Figure 11-17. SIO Output HighVoltage and Current,
Unregulated Mode
Figure 11-18. SIO Output Low Voltage and Current,
Unregulated Mode
Figure 11-19. SIO Output High Voltage and Current,
Regulated Mode
Table 11-12. SIO AC Specifications
Parameter
TriseF
Description
Conditions
Min
Typ
Max
Units
Rise time in Fast Strong Mode
(90/10%)[32]
Cload = 25 pF, VDDIO = 3.3 V
–
–
12
ns
TfallF
TriseS
TfallS
Fall time in Fast Strong Mode
(90/10%)[32]
Cload = 25 pF, VDDIO = 3.3 V
Cload = 25 pF, VDDIO = 3.0 V
Cload = 25 pF, VDDIO = 3.0 V
–
–
–
–
–
–
12
75
60
ns
ns
ns
Rise time in Slow Strong Mode
(90/10%)[32]
Fall time in Slow Strong Mode
(90/10%)[32]
Note
32. Based on device characterization (Not production tested).
