Regulatory Information
The HCPL-316J has been approved by the following
organizations:
UL
Recognized under UL 1577, component recognition pro-
gram, File E55361.
IEC/EN/DIN EN 60747-5-2
Approved under:
CSA
IEC 60747-5-2:1997 + A1:2002
EN 60747-5-2:2001 + A1:2002
DIN EN 60747-5-2 (VDE 0884 Teil 2):2003-01.
Approved under CSA Component Acceptance Notice #5,
File CA 88324.
IEC/EN/DIN EN 60747-5-2 Insulation Characteristics*
Description
Symbol
Characteristic
Unit
Installation classification per DIN VDE 0110/1.89, Table 1
for rated mains voltage ≤ 150 Vrms
for rated mains voltage ≤ 300 Vrms
I - IV
I - IV
I - III
for rated mains voltage ≤ 600 Vrms
Climatic Classification
55/100/21
Pollution Degree (DIN VDE 0110/1.89)
Maximum Working Insulation Voltage
2
VIORM
VPR
891
VPEAK
VPEAK
Input to Output Test Voltage, Method b**
VIORM x 1.875 = VPR, 100% Production Test with tm = 1sec,
Partial Discharge < 5 pC
1670
Input to Output Test Voltage, Method a**
VIORM x 1.5 = VPR, Type and Sample Test, tm = 60 sec,
Partial Discharge < 5 pC
VPR
1336
6000
VPEAK
VPEAK
Highest Allowable Overvoltage** (Transient Overvoltage tini = 10 sec)
VIOTM
Safety-limiting values – maximum values allowed in the event of a failure,
also see Figure 2.
Case Temperature
Input Power
TS
175
400
1200
°C
mW
mW
PS, INPUT
PS, OUTPUT
Output Power
Insulation Resistance at TS, VIO = 500 V
RS
>109
Ω
*Isolation characteristics are guaranteed only within the safety maximum ratings which must be ensured by protective circuits in application. Sur-
face mount classification is class A in accordance with CECCOO802.
**Refer to the optocoupler section of the Isolation and Control Components Designer’s Catalog, under Product Safety Regulations section IEC/
EN/DIN EN 60747-5-2, for a detailed description of Method a and Method b partial discharge test profiles.
1400
P , OUTPUT
S
1200
1000
P , INPUT
S
800
600
400
200
0
0
25 50 75 100 125 150 175 200
T
– CASE TEMPERATURE – °C
S
Figure 2. Dependence of safety limiting values on temperature.
