AT8xC51SND2C
Table 104. DAC Right Line In Gain Register - DAC_RLIG (02h)
7
6
5
4
3
2
1
0
-
-
-
RLIG4
RLIG3
RLIG2
RLIG1
RLIG0
Bit
Number
7:5
4:0
Description
Bit Mnemonic
-
Not used
Right channel line in analog gain selector
RLIG 4:0
Reset Value = 0000101b
Table 105. DAC Left Master Playback Gain Register - DAC_LMPG (03h)
7
6
5
4
3
2
1
0
-
-
LMPG5
LMPG4
LMPG3
LMPG2
LMPG1
LMPG0
Bit
Bit
Description
Mnemonic
Number
7:6
5:0
-
Not used
Left channel master playback digital gain selector
LMPG 5:0
Reset Value = 00001000b
Table 106. DAC Right Master Playback Gain Register - DAC_RMPG (04h)
7
6
5
4
3
2
1
0
-
-
RMPG5
RMPG4
RMPG3
RMPG2
RMPG1
RMPG0
Bit
Bit
Description
Mnemonic
Number
7:6
5:0
-
Not used
Right channel master playback digital gain selector
RMPG 5:0
Reset Value = 00001000b
Table 107. DAC Left Line Out Gain Register - DAC_LLOG (05h)
7
6
5
4
3
2
1
0
-
-
LLOG5
LLOG4
LLOG3
LLOG2
LLOG1
LLOG0
Bit
Bit
Description
Mnemonic
Number
7:6
-
Not used
Left channel line out digital gain selector
5:0
LLOG 5:0
Reset Value = 00000000b
