Table 108. DAC Rigth Line Out Gain Register - DAC_RLOG (06h)
7
6
5
4
3
2
1
0
-
-
RLOG5
RLOG4
RLOG3
RLOG2
RLOG1
RLOG0
Bit
Number
7:6
5:0
Bit
Mnemonic
Description
-
Not used
Right channel line out digital gain selector
RLOG 5:0
Reset Value = 00000000b
Table 109. DAC Output Level Control Register - DAC_OLC (07h)
7
6
5
4
3
2
1
0
RSHORT
ROLC2
RLOC1
RLOC0
LSHORT
LOLC2
LOLC1
LOLC0
Bit
Bit
Mnemonic Description
Number
Right channel short circuit indicator (persistent; after being set, bit is not
cleared automatically even after the short circuit is eliminated; must be
cleared by reset cycle or direct register write operation)
7
RSHORT
ROLC 2:0
LSHORT
LOLC 2:0
6:4
3
Right channel output level control selector
Left channel short circuit indicator (persistent; after being set, bit is not
cleared automatically even after the short circuit is eliminated; must be
cleared by reset cycle or direct register write operation)
2:0
Left channel output level control selector
Reset Value = 00100010b
