Strip Connectors
Series 105 - (Plastic) How to Order
Amphenol
Aerospace
Example:
105R21P-4A5A1
Description: Ryton material strip connector, size 21 plug, wire termination, 26 AWG, 7-strd per NEMA-HP3,
color coded per MIL-STD-681 (sys 1) ,18" long with one guide pin on one end of the connector.
105 R xxx x - x x x - x x xxx
Non Std. ꢅength (Inches)
Connector Series
Stranded Wire (no decimal values)
e.g. 1 = 1 inches, 100 = 100 inches
Solid Wire (0.109 < length < 1.00)
105 = Strip Connector
ꢀnsulator Material
e.g. 110 = .110 inches, 999 = .999 inches
ꢁ = Polyphenylene Sulfide (Ryton)
Guide pin
Numꢈer oꢇ Contacts
Guide pin for receptacle; guide pin hole for plug
1 to 30 (no guide pins)
1 = one end
2 = both end
1 to 29 (guide pin on one end)
1 to 28 (guide pin on both ends)
Omit for no guide pins
Connector Type
P = plug (pin)
S = Receptacle (socket)
wire ꢅength (inches +1.00/-0.00)
A = 18.00
b = 36.00
C = 72.00
wire Siꢉe (Aꢆg.)
1 = 32
2 = 30
D = 0.500 (solid wire only +0.20/-0.00)
ꢃ = 1.00 (solid wire only +0.20/-0.00)
f = non std. length (add to end of part no.)
Omit for solder cup contacts
3 = 28
4 = 26 (stranded)
5 = 25 (solid uninsulated)
6 = 24
wire Color / finish
1 = all white (M83513 standard) *off shelf
2 = all yellow
Omit for solder cup contacts
3 = solid wire uninsulated, tin plated
4 = solid wire uninsulated, gold plated
5 = color coded per mil-std-681, system 1
6 = 1st 10 colors blk. thru wht. repeated
(M83513 standard) *off shelf"
wire Type
Naꢊal Applications:
A = 7 strd, per NEMA-HP3 (MIL-W-16878/4)
b = 7 strd, per NEMA-HP3 (MIL-W-16878/6)
C = 19 strd, per NEMA-HP3 (MIL-W-16878/4)
D = 19 strd, per NEMA-HP3 (MIL-W-16878/6)
Military/Aerospace Applications:
ꢃ = per MIL-W-22759/11 (M83513 standard)
f = per MIL-W-22759/33 (space grade)
ꢅ = solid wire uninsulated
Omit for solder cup contacts
Omit for solder cup contacts
Features
• One piece insulator: Polyphenylene sulfide (Ryton)
• Contacts (1-30 positions): Copper alloy, gold plate
• Guide pin (optional, one or both ends): 300 series stainless steel
• Wide selection of wire sizes, types, and color finish.
• Coupling feature: Friction
• Contact spacing: .050" (1.27) center
Inches (mm)
All dimensions for reference only
Contact Amphenol Aerospace for more information at 800-678-0141 • www.amphenol-aerospace.com
