Strip Connectors
Series 105 - Plastic
Amphenol
Aerospace
.050" contact spacing
PLUG
RECEPTACLE
A
A
.050 (1.27) TYP
.050 (1.27) TYP
.075 .005
(1.91 0.13)
SKT 1 (USING GUIDE PIN)
SKT 1 (WITHOUT GUIDE PIN)
PIN 1 (USING GUIDE PIN HOLE)
PIN 1 (WITHOUT GUIDE PIN HOLE)
.075 .005
(1.91 0.13)
GUIDE PIN
(ONE/BOTH ENDS)
GUIDE PIN HOLE
(ONE/BOTH ENDS)
.032 .003 DIA
(0.81 0.08)
.185 .010
(4.70 0.25)
.126 .010
(3.20 0.25)
.283 .005
(7.19 0.13)
.125 .005
(3.18 0.13)
WIRE LENGTH
WIRE LENGTH
EPOXY
.125 (3.18) MAX
(INSULATED WIRE ONLY)
A
A
SIZE
SIZE
.005 (0.13)
.005 (0.13)
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
.075 (1.91)
.125 (3.18)
.175 (4.45)
.225 (5.72)
.275 (6.99)
.325 (8.25)
.375 (9.52)
.425 (10.80)
.475 (12.07)
.525 (13.34)
.575 (14.61)
.625 (15.88)
.675 (17.15)
.725 (18.42)
.775 (19.69)
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
.825 (20.96)
.875 (22.23)
.925 (23.50)
.975 (24.77)
1.025 (26.04)
1.075 (27.31)
1.125 (28.58)
1.175 (29.85)
1.225 (31.12)
1.275 (32.39)
1.325 (33.66)
1.375 (34.93)
1.425 (36.20)
1.475 (37.47)
1.525 (38.74)
Inches (mm)
All dimensions for reference only
Contact Amphenol Aerospace for more information at 800-678-0141 • www.amphenol-aerospace.com
