A49FL004
Table 3: FWH Write Cycle
Clock
Field
FWH[3:0]
Direction
Descriptions
Cycle
Start of Cycle: “1101b” to indicate the start of a memory write cycle.
FWH4 must be active (low) for the part to respond. Only the last
start field (before FWH4 transitioning high) should be recognized.
The START field contents indicate an FWH write cycle.
1
START
1101
IN
ID Select Cycle: Indicates which FWH device should respond. If the
IDSEL field matches the value set on ID[3:0] pins, then the particular
FWH device will respond to subsequent commands.
2
3-9
IDSEL
IMADDR
IMSIZE
DATA
0000 to 1111
YYYY
IN
IN
IN
Address Cycle: This is the 28-bit memory address. The addressed
transfer most-significant nibble first and least-significant nibble last.
(i.e., a27-24 on FWH[3:0] first, and A3-A0 on FWH[3:0] last).
Memory Size Cycle: Indicates how many bytes will be or transferred
during multi-byte operations. The A49FL004 only supports “0000b”
for one byte operation.
10
0000
Data Cycles: The 8-bits data transferred with least-significant nibble
first and most-significant nibble last. (i.e., I/O3 – I/O0 on FWH[3:0]
first, then I/O7 – I/O4 on FWH[3:0] last).
11-12
YYYY
1111
IN
IN
Turn-Around cycle 0: The master (Intel ICH) has driven the bus to
then Float all”1”s and then float the bus.
13
14
15
16
17
TAR0
TAR1
1111
(Float)
Float
Turn-Around cycle 1: The device takes control of the bus during this
then OUT cycle.
0000
(Ready)
Ready Sync: The FWH device indicates that it has received the data
or command.
RSYNC
TAR0
OUT
OUT
Turn-Around cycle 0: The FWH device has driven the bus to all “1”s
then Float and then float the bus.
1111
1111
(Float)
Float
Turn-Around cycle 1: The master (Intel ICH) resumes control of the
then IN bus during this cycle.
TAR1
Figure 5: FWH Write Waveforms
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
CLK
FWH4
START
IDSEL
IMADDR
IMSIZE
DATA
TAR0
TAR1
RSYNC
TAR0
TAR1
FWH[3:0]
PRELIMINARY
(September, 2005, Version 0.0)
8
