CSR15: Mode
SPND bit is set. Cleared by
H_RESET or S_RESET and is
unaffected by STOP.
This register’s fields are loaded during the Am79C978
controller initialization routine with the corresponding
Initialization Block values, or when a direct register write
has been performed on this register.
6
5
INTL
Internal Loopback. See the de-
scription of LOOP (CSR15, bit 2).
Bit
Name
Description
This bit is read/write accessible
only when either the STOP or the
SPND bit is set.
31-16 RES
Reserved locations. Written as
zeros and read as undefined.
DRTY
Disable Retry. When DRTY is set
to 1, the Am79C978 controller will
attempt only one transmission. In
this mode, the device will not pro-
tect the first 64 bytes of frame
data in the Transmit FIFO from
being overwritten, because auto-
matic retransmission will not be
necessary. When DRTY is set to
0, the Am79C978 controller will
attempt 16 transmissions before
signaling a retry error.
15
14
PROM
Promiscuous
PROM = 1, all incoming receive
frames are accepted.
Mode.
When
This bit is read/write accessible
only when either the STOP or the
SPND bit is set.
DRCVBC
Disable Receive Broadcast.
When
set,
disables
the
Am79C978 controller from re-
ceiving broadcast messages.
Used for protocols that do not
support broadcast addressing,
except as a function of multicast.
DRCVBC is cleared by activation
of H_RESET or S_RESET
(broadcast messages will be re-
ceived) and is unaffected by
STOP.
This bit is read/write accessible
only when either the STOP or the
SPND bit is set.
4
FCOLL
Force Collision. This bit allows
the collision logic to be tested.
The Am79C978 controller must
be in internal loopback for FCOLL
to be valid. If FCOLL = 1, a colli-
sion will be forced during loop-
back transmission attempts,
which will result in a Retry Error.
If FCOLL = 0, the Force Collision
logic will be disabled. FCOLL is
defined after the initialization
block is read.
This bit is read/write accessible
only when either the STOP or the
SPND bit is set.
13
DRCVPA
Disable Receive Physical Ad-
dress. When set, the physical ad-
dress detection (Station or node
ID) of the Am79C978 controller
will be disabled. Frames ad-
dressed to the nodes individual
physical address will not be rec-
ognized.
This bit is read/write accessible
only when either the STOP or the
SPND bit is set.
3
DXMTFCS Disable Transmit CRC (FCS).
When DXMTFCS is set to 0, the
transmitter will generate and ap-
pend an FCS to the transmitted
frame. When DXMTFCS is set to
1, no FCS is generated or sent
with the transmitted frame.
DXMTFCS is overridden when
ADD_FCS and ENP bits are set
in TMD1.
This bit is read/write accessible
only when either the STOP or the
SPND bit is set.
12-9
RES
Reserved locations. Written as
zeros and read as undefined.
8-7 PORTSEL[1:0] Port Select bits allow for software
controlled selection of the net-
work medium. The only legal val-
ues for this field is 11.
When the APAD_XMT bit (CSR4,
bit11) is set to 1, the setting of
DXMTFCS has no effect.
This bit is read/write accessible
only when either the STOP or the
Am79C978
127
