This bit is always read accessi-
ble. INTR is read only. INTR is
cleared by clearing all of the ac-
tive individual interrupt bits that
have not been masked out.
will be reset and no Transmit De-
scriptor Ring access will occur.
TDMD is required to be set if the
TXDPOLL bit in CSR4 is set. Set-
ting TDMD while TXDPOLL = 0
merely hastens the controller’s
response to a Transmit Descrip-
tor Ring Entry.
6
IENA
Interrupt Enable allows INTA to
be active if the Interrupt Flag is
set. If IENA = 0, then INTA will
be disabled regardless of the
state of INTR.
This bit is always read/write ac-
cessible. TDMD is set by writing a
1. Writing a 0 has no effect.
TDMD will be cleared by the Buff-
er Management Unit when it
fetches a Transmit Descriptor.
TDMD is cleared by H_RESET or
S_RESET and setting the STOP
bit.
This bit is always read/write ac-
cessible. IENA is set by writing a
1 and cleared by writing a 0. IENA
is cleared by H_RESET or
S_RESET and setting the STOP
bit.
5
RXON
Receive On indicates that the re-
ceive function is enabled. RXON
is set if DRX (CSR15, bit 0) is set
to 0 after the START bit is set. If
INIT and START are set together,
RXON will not be set until after
the initialization block has been
read in.
2
STOP
STOP assertion disables the chip
from all DMA activity. The chip re-
mains inactive until either STRT
or INIT are set. If STOP, STRT,
and INIT are all set together,
STOP will override STRT and
INIT.
This bit is always read accessi-
ble. RXON is read only. RXON is
This bit is always read/write ac-
cessible. STOP is set by writing a
1, by H_RESET or S_RESET.
Writing a 0 has no effect. STOP is
cleared by setting either STRT or
INIT.
cleared
by
H_RESET
or
S_RESET and setting the STOP
bit.
4
TXON
Transmit On indicates that the
transmit function is enabled.
TXON is set if DTX (CSR15, bit 1)
is set to 0 after the START bit is
set. If INIT and START are set to-
gether, TXON will not be set until
after the initialization block has
been read in.
1
STRT
STRT assertion enables the
Am79C978 controller to send and
receive frames and perform buff-
er management operations. Set-
ting STRT clears the STOP bit. If
STRT and INIT are set together,
the Am79C978 controller initial-
ization will be performed first.
This bit will reset if the DXSUFLO
bit (CSR3, bit 6) is reset and there
is an underflow condition encoun-
tered.
This bit is always read/write ac-
cessible. STRT is set by writing a
1. Writing a 0 has no effect. STRT
is
cleared
by
H_RESET,
Read accessible always. TXON
is read only. TXON is cleared by
H_RESET or S_RESET and set-
ting the STOP bit.
S_RESET, or by setting the
STOP bit.
0
INIT
INIT assertion enables the
Am79C978 controller to begin the
initialization procedure which
reads in the initialization block
from memory. Setting INIT clears
the STOP bit. If STRT and INIT
are set together, the Am79C978
controller initialization will be per-
3
TDMD
Transmit Demand, when set,
causes the Buffer Management
Unit to access the Transmit De-
scriptor Ring without waiting for
the poll-time counter to elapse. If
TXON is not enabled, TDMD bit
114
Am79C978
