STP = 1, then some descriptors/
buffers may be skipped in the
ring. While performing the search
for the next STP bit that is set to
1, the Am79C978 controller will
advance through the receive de-
scriptor ring regardless of the
state of ownership bits. If any of
the entries that are examined
during this search indicate
Am79C978 controller ownership
of the descriptor but also indicate
STP = 0, then the Am79C978
controller will reset the OWN bit
to 0 in these entries. If a scanned
entry indicates host ownership
See Appendix B for more infor-
mation on the Look Ahead Pack-
et Processing concept.
4
3
2
DXMT2PD Disable Transmit Two Part Defer-
ral (see Medium Allocation sec-
tion in the Media Access
Management section for more
details). If DXMT2PD is set,
Transmit Two Part Deferral will
be disabled.
This bit is always read/write ac-
cessible. DXMT2PD is cleared by
H_RESET or S_RESET and is
not affected by STOP.
with
STP = 0,
then
the
EMBA
Enable Modified Back-off Algo-
rithm (see the Contention Reso-
lution section in Media Access
Management section for more
details). If EMBA is set, a modi-
fied back-off algorithm is imple-
mented.
Am79C978 controller will not al-
ter the entry, but will advance to
the next entry.
When the STP bit is found to be
true, but the descriptor that con-
tains this setting is not owned by
the Am79C978 controller, then
the Am79C978 controller will stop
advancing through the ring en-
tries and begin periodic polling of
this entry. When the STP bit is
found to be true, and the descrip-
tor that contains this setting is
owned by the Am79C978 control-
ler, then the controller will stop
advancing through the ring en-
tries, store the descriptor infor-
mation that it has just read, and
wait for the next receive to arrive.
This bit is always read/write ac-
cessible. EMBA is cleared by
H_RESET or S_RESET and is
not affected by STOP.
BSWP
Byte Swap. This bit is used to
choose between big and little En-
dian modes of operation. When
BSWP is set to a 1, big Endian
mode is selected. When BSWP is
set to 0, little Endian mode is se-
lected.
When big Endian mode is select-
ed, the Am79C978 controller will
swap the order of bytes on the AD
bus during a data phase on ac-
cesses to the FIFOs only. Specif-
ically, AD[31:24] becomes Byte
0, AD[23:16] becomes Byte 1,
AD[15:8] becomes Byte 2, and
AD[7:0] becomes Byte 3 when
big Endian mode is selected.
When little Endian mode is se-
lected, the order of bytes on the
AD bus during a data phase is:
AD[31:24] is Byte 3, AD[23:16] is
Byte 2, AD[15:8] is Byte 1, and
AD[7:0] is Byte 0.
This behavior allows the host
software to pre-assign buffer
space in such a manner that the
header portion of a receive pack-
et will always be written to a par-
ticular memory area, and the data
portion of a receive packet will al-
ways be written to a separate
memory area. The interrupt is
generated when the header bytes
have been written to the header
memory area.
This bit is always read/write ac-
cessible. The LAPPEN bit will be
reset to 0 by H_RESET or
S_RESET and will be unaffected
by STOP.
Byte swap only affects data
transfers that involve the FIFOs.
Initialization block transfers are
not affected by the setting of the
