BSWP bit. Descriptor transfers
are not affected by the setting of
the BSWP bit. RDP, RAP, BDP
and PCI configuration space ac-
cesses are not affected by the
setting of the BSWP bit. Address
PROM transfers and Expansion
ROM accesses are not affected
by the setting of the BSWP bit.
13
12
RES
Reserved Location. Written as
zero and read as undefined.
TXDPOLL Disable Transmit Polling. If TXD-
POLL is set, the Buffer Manage-
ment Unit will disable transmit
polling. Likewise, if TXDPOLL is
cleared, automatic transmit poll-
ing is enabled. If TXDPOLL is set,
TDMD bit in CSR0 must be set in
order to initiate a manual poll of a
transmit descriptor. Transmit de-
scriptor polling will not take place
if TXON is reset. Transmit polling
will take place following Receive
activities.
Note that the byte ordering of the
PCI bus is defined to be little En-
dian. BSWP should not be set to
1 when the Am79C978 controller
is used in a PCI bus application.
This bit is always read/write ac-
cessible. BSWP is cleared by
H_RESET or S_RESET and is
not affected by STOP.
This bit is always read/write ac-
cessible. TXDPOLL is cleared by
H_RESET or S_RESET and is
unaffected by the STOP bit.
1-0
RES
Reserved locations. The default
values of these bits are zeros.
Writing a 1 to this bit has no effect
on device function. If a 1 is written
to these bits, then a 1 will be read
back. Existing drivers may write a
1 to these bits for compatibility,
but new drivers should write a 0
to these bits and should treat the
read value as undefined.
11
APAD_XMT Auto Pad Transmit. When set,
APAD_XMT enables the auto-
matic padding feature. Transmit
frames will be padded to extend
them to 64 bytes including FCS.
The FCS is calculated for the en-
tire frame, including pad, and ap-
pended after the pad field.
APAD_XMT will override the pro-
gramming of the DXMTFCS bit
(CSR15, bit 3) and of the
ADD_FCS bit (TMD1, bit 29).
CSR4: Test and Features Control
Certain bits in CSR4 indicate the cause of an interrupt.
The register is designed so that these indicator bits are
cleared by writing ones to those bit locations. This
means that the software can read CSR4 and write back
the value just read to clear the interrupt condition.
This bit is always read/write ac-
cessible. APAD_XMT is cleared
by H_RESET or S_RESET and is
unaffected by the STOP bit.
Bit
Name
Description
10
ASTRP_RCV Auto Strip Receive. When set,
ASTRP_RCV enables the auto-
matic pad stripping feature. The
pad and FCS fields will be
stripped from receive frames and
not placed in the FIFO.
31-16 RES
Reserved locations. Written as
zeros and read as undefined.
15
RES
Reserved location. It is OK for
legacy software to write a 1 to this
location. This bit must be set
back to 0 before setting INIT or
STRT bits.
This bit is always read/write ac-
cessible. ASTRP_RCV is cleared
by H_RESET or S_RESET and is
unaffected by the STOP bit.
This bit is always read/write ac-
cessible. This bit is cleared by
H_RESET or S_RESET and is
unaffected by the STOP bit.
9
MFCO
Missed Frame Counter Overflow
is set by the Am79C978 control-
ler when the Missed Frame
Counter (CSR112 and CSR113)
has wrapped around.
14
DMAPLUS Writing and reading from this bit
has no effect. DMAPLUS is al-
ways set to 1.
118
