10
9
D2_SPT
D1_SPT
D2 Support. If this bit is a 1, this
function supports the D2 Power
Management State.
before the generic class device
driver is able to use it.
This bit is read only.
Reserved location.
This bit is read only.
4
3
RES
D1 Support. If this bit is a 1, this
function supports the D1 Power
Management State.
PME_CLK PME Clock. When this bit is a 1,
it indicates that the function relies
on the presence of the PCI clock
for PME operation. When this bit
is a 0 it indicates that no PCI
clock is required for the function
to generate PME.
This bit is read only.
8-6
AUX_CURRENT
Auxiliary Current Requirements.
This 3-bit field reports the
3.3Vaux current requirements for
the PCI function. If the Data Reg-
ister has been implemented by
this function, then reads of this
field must return a value of 000b
and the Data Register will take
precedence over this field for
3.3Vaux current requirement re-
porting.
Functions that do not support
PME generation in any state
must return 0 for this field.
This bit is read only.
2-0
PMIS_VER Power Management Interface
Specification Version. A value of
001b indicates that this function
complies with revision 1.0 of the
PCI Power Management Inter-
face Specification.
If PME generation from D3cold is
not supported by the function
(PMC (15) = 0), this field must re-
turn a value of 000b when read.
PCI Power Management Control/Status Register
(PMCSR)
Offset 44h
For functions that support PME
from D3cold and do not implement
the Data Register, the following
bit assignments apply:
Bit
Name
Description
15 PME_STATUS PME Status. This bit is set when
the function would normally as-
sert the PME signal independent
of the state of the PME_EN bit.
Bit
8 7 6
3.3Vaux
Max. Current Required
1 1 1
1 1 0
1 0 1
1 0 0
0 1 1
0 1 0
0 0 1
0 0 0
375 mA
320 mA
Writing a 1 to this bit will clear it
and cause the function to stop as-
serting a PME (if enabled). Writ-
ing a 0 has no effect.
270 mA
220 mA
If the function supports PME from
D3cold, then this bit is sticky and
must be explicitly cleared by the
operating system each time the
operating system is initially load-
ed.
160 mA
100 mA
55 mA
0 (self-powered)
This bit is always read/write ac-
cessible. Sticky bit. This bit is re-
These bits are read only.
set
by
POR.
H_RESET,
5
DSI
Device Specific Initialization.
When this bit is 1, it indicates that
special initialization of the func-
tion is required (beyond the stan-
dard PCI configuration header)
S_RESET, or setting the STOP
bit has no effect.
110
Am79C978
