Revision J – April 7, 2006
S2004 – Quad Serial Backplane Device
Data Sheet
S2004 – 208 PBGA PACKAGE MARKING DRAWING
Figure 15. S2004 – 208 PBGA Package Marking Drawing (Top View)
NOTES (Unless Otherwise Specified):
Dot Represents PIN 1 (A01) Designator
1
ES (Engineering Sample) designator. When present, this signifies
pre-production grade material. Pre-production grade material is not
2
guaranteed to meet the specifications in this document.
1
S2004 UUUUU
M
XXYY
ZZZZZZM
WWWWW
e1
ES
2
LEGEND (in row order - including symbols):
ROW#1:
AMCC Logo
ROW#2:
AMCCDevicePartNumber
S2004: Core Part Number
UUUUU: Ordering Options (eg. package identifier, lead f ree, speed grade, ...). Character
Length may v ary Dependingon Options Selected.
ROW#3:
M
MaskProtectionSy mbol
XX: As s em bly Y ear C ode
YY: Assembly Week Code
ROW#4:
ROW#5:
ZZZZZZ: AMCC 6Digit LotCode
M: Mask Set Rev isionCode
ESDSy mbol
WWWWW: Assembly Location
ROW#6:
e1
RoHSLead FreeCompliant Sy mbol(perJEDEC: JESD97). When present, this signif ies alead f reepackage.
AMCC Confidential and Proprietary
33
