Automatic Analysis Function
On a graphics plot, the markers and lines
can be automatically located using the
auto analysis setup. Parameters can be
automatically determined using automatic
analysis, user function, and read out
functions.
Hard Copy via Network Interface
The network interface has lpr client
capability.
Repeating and Automating Test
Instrument Control
Agilent 4155C and 4156C function
control:
High-Resolution (HR) Mode
This file mode is available for cases where
an extremely clean print-out or plot is
Internal or external computer controls
the 4155C and 4156C functions via the
GPIB interface
desired.
Note: High-resolution mode takes significantly greater
CPU time to generate, so its use is recommended for
final reports only.
User Variable
Command sets:
SCPI command set
Agilent FLEX command set
Agilent 4145B command set
Program Memory:
Display the data on the LCD via GPIB or
instrument BASIC.
Data Storage
Mass storage device:
Output
Display
Using the Agilent FLEX command set,
the user can store program code in
the 4155C or the 4156C. The maximum
number of subprograms is 255 (8 bit).
External instrument remote control:
Control external equipment via the GPIB
interface.
Built-in 3.5-inch floppy disk drive
Media: 3.5-inch 2HD or 2DD diskette
Format type: HP LIF and DOS
User area: 1.44 Mbyte (2HD) or
720 Kbyte (2DD)
Display Modes
Graphics and list.
Graphics Display
X-Y or X-Y1/Y2 plot of source current/
voltage, measured current/voltage, time,
or calculated USER FUNCTION data.
List Display
File types:
Auto start program file, initial setup file,
measurement setup file, measurement
setup/result file, stress setup file,
customize file, hard copy data file, and
Instrument BASIC program and data file.
Format of data made by the HP BASIC
program:
Instrument BASIC
Measurement data and calculated USER
FUNCTION data are listed in conjunction
with VAR1 step number or time domain
sampling step number. Up to eight data
sets can
Instrument BASIC is a subset of
HP BASIC.
Functions:
Arithmetic operation, binary operation,
string manipulation, logical operation,
array operation, program flow control,
event-initiated branching, program
editing and debugging support, mass
storage operation, instrument control,
real-time clock, softkey operation, and
graphics.
be displayed.
Display
Data made by the HP BASIC program
and data made by the Instrument BASIC
program are compatible.
Network mass storage device:
An NFS mountable mass storage device
File types:
8.4-inch diagonal color active matrix LCD,
640 dot (H ꢁ 480 dot (V). More than ++.++ꢀ
of the pixels on an LCD are active.
Hard Copy Functions
Auto start program file, initial setup file,
measurement setup file, measurement
setup/result file, stress setup file,
customize file, and hard copy data file.
Maximum number of files allowed per
directory on network mass storage device:
1++
Graphics Hard Copy
Agilent 4145B automatic sequence
program (ASP) typing aid:
Measured data and all data appearing on
the LCD can be output via GPIB, parallel
printer port, or network interface to
supported HP plotters or printers. PCL,
HR PCL (high-resolution PCL), and HP-GL
formats are supported (selectable).
Text Hard Copy
4145B ASP-like syntax softkeys are
available in instrument BASIC. A 4145B
ASP file cannot be read by the 4155C or
4156C.
Remote control:
Data storage (supplemental data):
2HD DOS format:
Instrument BASIC is remote controllable
from an external computer via the GPIB
interface.
Print out setup information or measured
data list as ASCII text via GPIB, parallel
printer port, or network interface to
supported HP plotters or printers. PCL,
HR PCL, and HP GL formats are supported
(selectable).
Available bytes: 1457 K (byte)
File size:
Instrument BASIC memory area (supple-
mental data):
Measurement setup: 3843 (byte)
Stress setup: 601 (byte)
Program (text) area: 16 K (byte)
Variable/stack area: 500 K (byte)
Measurement setup/result
(Typical data): 15387 (byte)
(VAR1: 101, VAR2: 5)
Hard Copy File
Common variable area: 600 K (byte)
Note: The memory size for common variable is
decreased when hard copy or disk operation is
performed.
Hard copy output can be stored to an
internal or external mass storage device
instead of sending it to a printer or plotter.
The data can be stored in PCL, HR PCL,
TIFF, HR TIFF (highresolution TIFF), or
HP GL formats.
Customized system setup:
1661 (byte)
Hardcopy data: 30317 (byte)
(Monochrome PCL 75DPI file)
Hardcopy data: 38702 (byte)
(monochrome TIFF file)
Note: For LIF format, the total number of files is limited
to 1++.
8
