Waveform Generator, Trapezoid DC Level 2 Register—WGDCLEVEL2
Address 0x0000201C, Reset: 0x00000000, Name: WGDCLEVEL2
Table 116. Bit Descriptions for WGDCLEVEL2 Register
Bits
[31:12]
[11:0]
Bit Name
Reserved
TRAPDCLEVEL2
Settings
Description
Reserved.
Reset
0x0
0x0
Access
R
R/W
DC Level 2 value for trapezoid waveform generation.
Waveform Generator, Trapezoid Delay 1 Time Register—WGDELAY1
Address 0x00002020, Reset: 0x00000000, Name: WGDELAY1
Table 117. Bit Descriptions for WGDELAY1 Register
Bits
[31:20] Reserved
[19:0] DELAY1
Bit Name Settings
Description
Reserved.
Reset
0x0
0x0
Access
R
R/W
Delay 1 value for trapezoid waveform generation. The unit of time is the DAC
update rate.
Waveform Generator, Trapezoid Slope 1 Time Register—WGSLOPE1
Address 0x00002024, Reset: 0x00000000, Name: WGSLOPE1
Table 118. Bit Descriptions for WGSLOPE1 Register
Bits
[31:20] Reserved
[19:0] SLOPE1
Bit Name Settings Description
Reset Access
Reserved.
0x0
R
Slope 1 value for trapezoid waveform generation. The unit of time is the DAC update 0x0
rate. For trapezoid generation, the DAC update rate is fixed to 320 kHz.
R/W
Waveform Generator, Trapezoid Delay 2 Time Register—WGDELAY2
Address 0x00002028, Reset: 0x00000000, Name: WGDELAY2
Table 119. Bit Descriptions for WGDELAY2 Register
Bits
[31:20] Reserved
[19:0] DELAY2
Bit Name Settings Description
Reset Access
Reserved.
0x0
0x0
R
R/W
Delay 2 value for trapezoid waveform generation. The unit of time is the DAC
update rate. For trapezoid generation, the DAC update rate is fixed to 320 kHz.
Waveform Generator, Trapezoid Slope 2 Time Register—WGSLOPE2
Address 0x0000202C, Reset: 0x00000000, Name: WGSLOPE2
Table 120. Bit Descriptions for WGSLOPE2 Register
Bits
[31:20] Reserved
[19:0] SLOPE2
Bit Name Settings Description
Reset Access
Reserved.
0x0
R
Slope 2 value for trapezoid waveform generation. The unit of time is the DAC update 0x0
rate. For trapezoid generation, the DAC update rate is fixed to 320 kHz.
R/W
