ADSP-BF542/ADSP-BF544/ADSP-BF547/ADSP-BF548/ADSP-BF549
Table 12. Pin Descriptions (Continued)
Driver
Type2
Pin Name
I/O1 Function (First/Second/Third/Fourth)
Port F: GPIO/PPI0/Alternate ATAPI Data
PF0/PPI0_D0/ATAPI_D0A
PF1/PPI0_D1/ATAPI_D1A
PF2/PPI0_D2/ATAPI_D2A
PF3/PPI0_D3/ATAPI_D3A
PF4/PPI0_D4/ATAPI_D4A
PF5/PPI0_D5/ATAPI_D5A
PF6/PPI0_D6/ATAPI_D6A
PF7/PPI0_D7/ATAPI_D7A
PF8/PPI0_D8/ATAPI_D8A
PF9/PPI0_D9/ATAPI_D9A
PF10/PPI0_D10/ATAPI_D10A
PF11/PPI0_D11/ATAPI_D11A
PF12/PPI0_D12/ATAPI_D12A
PF13/PPI0_D13/ATAPI_D13A
PF14/PPI0_D14/ATAPI_D14A
PF15/PPI0_D15/ATAPI_D15A
I/O GPIO/PPI0 Data/Alternate ATAPI Data
I/O GPIO/PPI0 Data/Alternate ATAPI Data
I/O GPIO/PPI0 Data/Alternate ATAPI Data
I/O GPIO/PPI0 Data/Alternate ATAPI Data
I/O GPIO/PPI0 Data/Alternate ATAPI Data
I/O GPIO/PPI0 Data/Alternate ATAPI Data
I/O GPIO/PPI0 Data/Alternate ATAPI Data
I/O GPIO/PPI0 Data/Alternate ATAPI Data
I/O GPIO/PPI0 Data/Alternate ATAPI Data
I/O GPIO/PPI0 Data/Alternate ATAPI Data
I/O GPIO/PPI0 Data/Alternate ATAPI Data
I/O GPIO/PPI0 Data/Alternate ATAPI Data
I/O GPIO/PPI0 Data/Alternate ATAPI Data
I/O GPIO/PPI0 Data/Alternate ATAPI Data
I/O GPIO/PPI0 Data/Alternate ATAPI Data
I/O GPIO/PPI0 Data/Alternate ATAPI Data
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
Port G: GPIO/PPI0/SPI1/PPI2/Up-Down
Counter/CAN0–1/Host DMA/MXVR (MOST)/ATAPI
PG0/PPI0_CLK/TMRCLK
PG1/PPI0_FS1
PG2/PPI0_FS2/ATAPI_A0A
PG3/PPI0_D16/ATAPI_A1A
PG4/PPI0_D17/ATAPI_A2A
PG5/SPI1SEL1/HOST_CE/PPI2_FS2/CZM
I/O GPIO/PPI0 Clock/External Timer Reference
I/O GPIO/PPI0 Frame Sync 1
I/O GPIO/PPI0 Frame Sync 2/Alternate ATAPI Address
I/O GPIO/PPI0 Data/Alternate ATAPI Address
I/O GPIO/PPI0 Data/Alternate ATAPI Address
A
A
A
A
A
I/O GPIO/SPI1SlaveSelect/HostDMAChipEnable/PPI2 FrameSync2/Counter A
Zero Marker
PG6/SPI1SEL2/HOST_RD/PPI2_FS1
PG7/SPI1SEL3/HOST_WR/PPI2_CLK
PG8/SPI1SCK
PG9/SPI1MISO
PG10/SPI1MOSI
PG11/SPI1SS/MTXON
PG12/CAN0TX
PG13/CAN0RX/TACI4
PG14/CAN1TX
I/O GPIO/SPI1 Slave Select/ Host DMA Read/PPI2 Frame Sync 1
I/O GPIO/SPI1 Slave Select/Host DMA Write/PPI2 Clock
I/O GPIO/SPI1 Clock
I/O GPIO/SPI1 Master In Slave Out
I/O GPIO/SPI1 Master Out Slave In
I/O GPIO/SPI1 Slave Select Input/MXVR Transmit Phy On
I/O GPIO/CAN0 Transmit
I/O GPIO/CAN0 Receive/Alternate Capture Input 4
I/O GPIO/CAN1 Transmit
A
A
C
C
C
A
A
A
A
A
PG15/CAN1RX/TACI5
I/O GPIO/CAN1 Receive/Alternate Capture Input 5
Rev. C
|
Page 29 of 100
|
February 2010
