SHW[7:0] Initial value: 0011_1111; Setting range: 0000_0001 to 1111_1111
Sets an OHS Sync. signal width of the internal SYNC generator.
The setting unit is one pixel.
Table R2-6-2(3) OHS Width Adjustment Settings
OHS width
SHW[7:0] = 01h
1(OCLK)
……
……
SHW[7:0] = 3Fh
63 (OCLK)
……
……
SHW[7:0] = FFh
255 (OCLK)
SYDL[7:0] Initial value: 0000_0000; Setting range: 0000_0001 to 1111_1111
Sets Sync. output delay adjustment of the internal SYNC generator.
Table R2-6-2(4) Synchronous Delay Adjustment Settings
OHS width
SYDL[7:0] = 00h
0 (OCLK)
SYDL[7:0] = 80h
128 (OCLK)
SYDL[7:0] = FFh
255 (OCLK)
……
……
……
……
VSYM[1:0] Initial value: 00; Setting range: Refer to Tables 2-4-1 (5) and 2-4-1 (6)
Sets a vertical Sync. signal option.
Table R2-6-2(5) Vertical Sync. Signal Setting 1
VSYM[0]
Analog vertical Sync. signal width
2.5H (625 lines), 3H(525 lines)
1.5H
0
1
Table R2-6-2(6) Vertical Sync. Signal Setting 2
VSYM[1]
525i digital vertical Sync. signal width
0
19H
1
9H
DSYNC Initial value: 0; Setting range: 0 to 1
Sets Sync. signal output for the OVS, OHS, and HREF digital pins.
Table R2-6-2(7) Vertical Sync. Signal Setting
DSYNC
Synchronous output
Analog Sync. signal
Digital Sync. signal
0
1
