FEDL87V2107-01
OKI Semiconductor
ML87V2107
2.7.3 Read NR Setting Values
SUB_ADDRESS = 73h(R): Luminance noise convergence level read register
DATA_BIT
BIT7
BIT6
BIT5
BIT4
BIT3
BIT2
BIT1
1
BIT0
0
RYNS
Register name
0
0
5
4
3
2
SUB_ADDRESS = 74h(R): Chrominance noise convergence level read register
DATA_BIT
BIT7
BIT6
BIT5
BIT4
BIT3
BIT2
BIT1
1
BIT0
0
RCNS
Register name
0
0
5
4
3
2
SUB_ADDRESS = 75h(R): Luminance noise upper limit level read register
DATA_BIT
BIT7
BIT6
BIT5
BIT4
BIT3
BIT2
RYLM
2
BIT1
1
BIT0
0
RYNR
OFF
Register name
RYABN RYNRM
4
3
SUB_ADDRESS = 76h(R): Chrominance noise upper limit level read register
DATA_BIT
BIT7
BIT6
BIT5
BIT4
BIT3
BIT2
RCLM
2
BIT1
1
BIT0
0
RCNR
OFF
Register name
RCABN RCNRM
4
3
SUB_ADDRESS = 77h(R): Luminance motion compensation level read register
DATA_BIT
BIT7
BIT6
RYMOF
2
BIT5
BIT4
BIT3
BIT2
2
BIT1
BIT0
0
RYMS
RNR2
OFF
Register name
3
1
3
1
RYNS[5:0] Read value range: 00_0000 to 11_1111
Reads luminance noise convergence level of internal operation state.
RYNS[5:0] = YNS[5:0] in case either the auto mode is not set (NRAUTO = 0) or the follow-up is not set
in the auto mode (AYNS[0] = 0).
RCNS[5:0] Read value range: 00_0000 to 11_1111
Reads chrominance noise convergence level of internal operation state.
RCNS[5:0] = CNS[5:0] in case either the auto mode is not set (NRAUTO = 0) or the follow-up is not set
in the auto mode (ACNS[0] = 0).
RYLM[5:0] Read value range: 0_0000 to 1_1111
Reads luminance noise upper limit level of internal operation state.
RYLM[4:0] = YLM[4:0] in case either the auto mode is not set (NRAUTO = 0) or the follow-up is not
set in the auto mode (AYLM[0] = 0).
RYNROF Read value range: 0 to 1
Reads luminance NR On/Off switching signal of internal operation state.
In case the auto mode is not set (NRAUTO = 0): RYNROFF = NROFF
RYNRM Read value range: 0 to 1
Reads luminance motion detection noise mode 0 switching signal of internal operation state.
In case the auto mode is not set (NRAUTO = 0): RYNRM = YNRM
146/152
