Ver 1.3
PRELIMINARY
EAGLE
3 REGISTER DESCRIPTIONS
The built-in AE32000C CPU in EAGLE is designed with 32-bit address.
If the memory region of EAGLE does not use TLB, it has a total of 512 MBytes external memory region. Table 3-1 shows
the memory allocation.
Each bank is allocated with 64 MBytes of memory region (except Bank 7 which is allocated with 128 MBytes of memory
region), and any 64 MBytes space can be designated and used as a selected bank. For example, any 64 MBytes space
between “2000 0000h” and “3FFF FFFFh” can be designated as Bank 1.
The memory range from FFE2 0000h to FFEF FFFFh which supports retry for AHB peripheral is currently not defined. The
memory range from FFF0 0000h to FFFE FFFFh is not defined as well. Software must not access these memory ranges. If
attempted, bus error will occur.
* Notice
SDRAM with full page burst mode must be used.
Address
Description
Size
64MB
2KB
ROM, SRAM
~ 1EFF:FFFFh
0000 0000h
Bank 0
(CS0x)
1F00 0000h ~ 1F00 07FFh
Inside 2K SRAM
1F00:0000h ~ 1F00:03FFh lower 1kb
1F00:0400h ~ 1F00:07FFh higher 1kb
Reserved
1F00 0800h ~ 1FFF FFFFh
2000 0000h
4000 0000h
6000 0000h
8000 0000h
A000 0000h
ROM, SRAM Bank 1 (CS1x)
ROM, SRAM Bank 2 (CS2x)
ROM, SRAM Bank 3 (CS3x)
ROM, SRAM Bank 4 (CS4x)
ROM, SRAM, SDRAM Bank 5 (CS5x)
64MB
64MB
64MB
64MB
64MB
64MB
128MB
C000 0000h
E000 0000h
ROM, SRAM, SDRAM Bank 6 (CS6x)
Texture Memory Bank
~ FFDF FFFF
SDRAM Bank 7 (TSD_CSx, TSD_CSx2)
FFE0 0000h ~ FFE0 FFFFh
FFE1 0000h ~ FFE1 FFFFh
FFE2 0000h ~ FFEF FFFFh
FFF0 0000h ~ FFFE FFFFh
FFFF 0000h ~ FFFF FFFFh
EAGLE Registers
64KB
64KB
EAGLE Registers
Reserved : Retry Slave
Reserved : Default Salve
OSI ROM
64KB
Table 3-1 EAGLE Memory Map (Normal Boot)
Address
Description
Size
Inside 2K SRAM
0000:0000h ~ 0000:03FFh lower 1kb
0000:0400h ~ 0000:07FFh higher 1kb
Bank 0
(CS0x)
0000 0000h ~ 0000 07FFh
2KB
0000 0800h ~ 1FFF FFFFh
2000 0000h
Reserved
ROM, SRAM Bank 1 (CS1x)
ROM, SRAM Bank 2 (CS2x)
ROM, SRAM Bank 3 (CS3x)
ROM, SRAM Bank 4 (CS4x)
ROM, SRAM, SDRAM Bank 5 (CS5x)
ROM, SRAM, SDRAM RAM Bank 6 (CS6x)
64MB
64MB
64MB
64MB
64MB
64MB
128MB
4000 0000h
6000 0000h
8000 0000h
A000 0000h
C000 0000h
E000 0000h
Texture Memory Bank
~ FFDF FFFF
SDRAM Bank 7 (TSD_CSx, TSD_CSx2)
FFE0 0000h ~ FFE0 FFFFh
FFE1 0000h ~ FFE1 FFFFh
FFE2 0000h ~ FFEF FFFFh
FFF0 0000h ~ FFFE FFFFh
FFFF 0000h ~ FFFF FFFFh
EAGLE Registers
EAGLE Registers
Reserved : Retry Slave
Reserved : Default Salve
OSI ROM
64KB
64KB
64KB
Table 3-2 EAGLE Memory Map (Auto Boot)
33
