The register range of EAGLE starts from FFE0 0000h. The AHB and APB registers are grouped under memory mapped
I/O registers. Table 3-4 shows the detailed register descriptions.
Offset Address
FFE0 0000h
FFE0 0400h
FFE0 0800h
FFE0 0C00h
FFE0 1000h
FFE0 1400h
FFE0 1800h
FFE0 1C00h
FFE0 2000h
FFE0 2400h
FFE0 3000h
FFE0 4000h
FFE0 4400h
FFE0 4800h
FFE0 4C00h
FFE0 5000h
FFE0 5400h
FFE0 5800h
FFE0 5C00h
~ FFE0 7FFF
FFE0 8000h
FFE0 8400h
FFE0 8800h
FFE0 8C00h
FFE0 9000h
FFE0 9400h
FFE0 9800h
FFE0 9C00h
FFE0 A000h
FFE0 A400h
FFE0 A800h
FFE0 AC00h
FFE0 B000h
FFE0 B400h
~ FFE0 FFFFh
FFE1 0000h
FFE2 0000h
~ FFEF FFFFh
Block
Remark
Bus Connection
APB
AHB
(SP00) System & Pin Mux
(SH01) Local Memory Controller
(SH02) DMA Controller
(SH03) Interrupt Controller
(SH04) Nand Flash Controller
(SH05) CRT Controller
(SH06) Graphic Engine
(SH07) H264
(SH08) PLL & Power Manager
(SH09) SDC
(SH10) Sound Mixer
(SH11) GUN Controller
(SH12) Video Encoder
(SH13) CSC ICE
ROM, SDRAM, SRAM
2 Channels
32 Sources
(SH14) OSD
(SH15) JPEG ICE
(SH17) USB Host Controller
(SH18) YC ICE
Reserved
(SP01) UART
4 Channels
5 * 5
APB
(SP02) Reserved
(SP03) Reserved
(SP04) Key Scan
(SP05) Reserved
(SP06) I2S
(SP07) USB Device Controller
(SP08) Watch Dog Timer
(SP09) Timer/PWM/Capture
(SP10) GPIO
(SP11) RTC
(SP12) TWI
(SP13) SPI
Reserved
4 Channels
(SH16) JPEG Decoder
Reserved
AHB
Table 3-4 EAGLE Register Offset Address
