EAGLE
PRELIMINARY
Ver 1.3
3.29.5 JPEG DECODER Y DC NODE Table (JDYDCNT)
Address : FFE1 0800h ~FFE1 0830h
Bit
31 : 18
17 : 0
R/W
R
W
Description
Default Value
Reserved
-
-
Y DC Node Table for Huffman Decoding
The node table of Y DC binary tree used for Huffman decoding
3.29.6 JPEG DECODER Y DC LEAF Table (JDYDCLT)
Address : FFE1 0C00h ~FFE1 0C30h
Bit
31 : 8
7 : 0
R/W
R
W
Description
Default Value
Reserved
-
-
Y DC LEAF Table for Huffman Decoding
The leaf table of Y DC binary tree used for Huffman decoding
3.29.7 JPEG DECODER Y AC NODE Table (JDYACNT)
Address : FFE1 2800h ~FFE1 2A88h
Bit
31 : 18
17 : 0
R/W
R
W
Description
Default Value
Reserved
-
-
Y AC Node Table for Huffman Decoding
The node table of Y AC binary tree used for Huffman decoding
3.29.8 JPEG DECODER Y AC LEAF Table (JDYACLT)
Address : FFE1 3000h ~FFE1 3288h
Bit
31 : 8
7 : 0
R/W
R
W
Description
Default Value
Reserved
-
-
Y AC LEAF Table for Huffman Decoding
The leaf table of Y AC binary tree used for Huffman decoding
3.29.9 JPEG DECODER UV DC NODE Table (JDUVDCNT)
Address : FFE1 4800h ~FFE1 4830h
Bit
31 : 18
17 : 0
R/W
R
W
Description
Default Value
Reserved
-
-
UV AC Node Table for Huffman Decoding
The node table of UV DC binary tree used for Huffman decoding
3.29.10 JPEG DECODER UV DC LEAF Table (JDUVDCLT)
Address : FFE1 5000h ~FFE1 5030h
Bit
31 : 8
7 : 0
R/W
R
W
Description
Default Value
Reserved
-
-
UV DC LEAF Table for Huffman Decoding
The leaf table of UV DC binary tree used for Huffman decoding
3.29.11 JPEG DECODER UV AC NODE Table (JDUVACNT)
Address : FFE1 6800h ~FFE1 6A88h
Bit
31 : 18
17 : 0
R/W
R
W
Description
Default Value
Reserved
-
-
UV AC Node Table for Huffman Decoding
The node table of UV AC binary tree used for Huffman decoding
3.29.12 JPEG DECODER UV AC LEAF Table (JDUVACLT)
Address : FFE1 7000h ~FFE1 7288h
Bit
31 : 8
7 : 0
R/W
R
W
Description
Default Value
Reserved
-
-
UV AC LEAF Table for Huffman Decoding
The leaf table of UV AC binary tree used for Huffman decoding
Beijing Peak Microtech Co.Ltd.
CONFIDENTIAL
216
