3.22.2.17 USB High Byte Out Write Count Register (USBHBOWC)
Address : 0xFFE0_9844h
Bit
R/W
Description
Default
Value
-
00h
31 : 8
7 : 0
R
R/W
Reserved
(HBOWC) High Byte OEP write count register
3.22.2.18 EP0 FIFO Data Register (USBEP0D)
Address : 0xFFE0_9848h
Bit
R/W
Description
Description
Description
Description
Description
Default
Value
-
31 : 8
7 : 0
R
R/W
Reserved
EP0 FIFO Data Register
00h
3.22.2.19 EP1 FIFO Data Register (USBEP1D)
Address : 0xFFE0_984Ch
Bit
R/W
Default
Value
-
31 : 8
7 : 0
R
R/W
Reserved
EP1 FIFO Data Register
00h
3.22.2.20 EP2 FIFO Data Register (USBEP2D)
Address : 0xFFE0_9850h
Bit
R/W
Default
Value
-
31 : 8
7 : 0
R
R/W
Reserved
EP2 FIFO Data Register
00h
3.22.2.21 EP3 FIFO Data Register (USBEP3D)
Address : 0xFFE0_9854h
Bit
R/W
Default
Value
-
31 : 8
7 : 0
R
R/W
Reserved
EP3 FIFO Data Register
00h
3.22.2.22 EP4 FIFO Data Register (USBEP4D)
Address : 0xFFE0_9858h
Bit
R/W
Default
Value
-
31 : 8
7 : 0
R
R/W
Reserved
EP4 FIFO Data Register
00h
