The Rendering X Start Point register configures the X coordinate of captured image displayed on screen.
This register provides a 16-Pixel offset for image size in X coordination.
3.16.8 Rendering Y Start Point Register (JICYSP)
Address : 0xFFE0 500C
Bit
31:10
9:1
R/W
R
R/W
R
Description
Default Value
Reserved
-
000h
-
Y Display Start Coordinate [9:1] ( Vertical 2 Pixel Offset )
Reserved
0
The Rendering Y Start Point register configures the Y coordinate of captured image displayed on screen.
This register provides a 2-line offset for image size in Y coordination.
3.16.9 Rendering Base Start Address Register (JICBSA)
Address : 0xFFE0 5010
Bit
31:20
19:0
R/W
R/W
R
Description
Default Value
Rendering Base Start Address
Reserved
000h
-
This register indicates the base address for storing the decoded JPEG Images. When bit 4 of Control register is set as
‘0’( Separate Address Use ), the Rendering Base Start Address should be specified. When bit 4 of Control Register is set as
‘1’( Image Capture Engine Frame Buffer Use ), the value of this register has no affect.
Both Local and Texture memory are supported. For Texture memory, bit 5 of Control Register should be set to ‘1’.
The Rendering Base Start Address Register is set using 1 MByte unit.
3.16.10 Rendering Status Register (JICSTAT)
Address : 0xFFE0 5014
Bit
31
30:28
27:16
15:12
11:0
R/W
R
R
R
R
Description
Default Value
Interrupt Status
Reserved
X Image Size / 32
Reserved
0b
-
000h
-
R
Y Image Size / 32
000h
Interrupt Status bit indicates whether the operation of writing one frame image into Memory has completed or not. This bit
is set to one whenever a frame image is written into memory. This bit will be cleared when bit 2 of JPEG Decoder Command
Control register is asserted to ‘1’.
The value in X / Y Image Size register is not the real image size value. The real image size value can be calculated by
multiplying X / Y Size with 32. For example, when X Image Size Register has a value of 20, the Real X Image Size shall be
640 (20 x 32).
3.16.11 Rendering Y Offset Address Register (JICYOFFA)
Address : 0xFFE0 5018
Bit
31:11
10:5
4:0
R/W
R
R/W
R
Description
Default Value
Reserved
Y Offset Address
Reserved
-
00h
-
149
