LC5200 Series
■External Dimensions (DIP8)
■Pin Assignment
(Unit : mm)
Pin No.
Symbol
Reg
Function
1
2
3
4
5
6
7
8
12-V Reg output pin
CR connection pin for setting PWM
Reference voltage input pin for controlling PWM
Load current sense pin
Load output pin
PWM
Ref
Sen
9.4 0.3
8
5
OUT
VBB
NC
Main power supply pin
Pin removed
GND
Device ground pin
1
4
1.52
+0.3
-0.05
+0.3
-0.05
1.0
7.6TYP
2.54TYP
0~15° 0~15°
0.89TYP
0.5 0.1
