Cable Assembly Instruction J
Crimp-crimp
STEP 1.
STEP 2.
STEP 3.
All parts of the connector are shown.
A crimp tool is necessary to complete the connection.
Strip the cable inner conductor, dielectric, braid, and jacket as per
"RECOMMENDED CABLE STRIPPING DIM'S" in catalog.
Insert inner conductor into the CONTACT PIN and solder on the
cable. Then slide the FERRULE onto cable.
STEP 4.
STEP 5.
Insert the MAIN BODY into braid and dielectric.
Slide the FERRULE over braid, crimp it with the crimp tool
as shown.
218
