ST90158 - EIGHT-CHANNEL ANALOG TO DIGITAL CONVERTER (A/D)
ANALOG TO DIGITAL CONVERTER (Cont’d)
9.8.4 Register Description
7
0
DATA REGISTERS (DiR)
D3.7 D3.6 D3.5 D3.4 D3.3 D3.2 D3.1 D3.0
The conversion results for the 8 available chan-
nels are loaded into the 8 Data registers following
conversion of the corresponding analog input.
CHANNEL 4 DATA REGISTER (D4R)
R244 - Read/Write
Register Page: 63
CHANNEL 0 DATA REGISTER (D0R)
R240 - Read/Write
Register Page: 63
Reset Value: undefined
7
0
Reset Value: undefined
7
0
D4.7 D4.6 D4.5 D4.4 D4.3 D4.2 D4.1 D4.0
D0.7 D0.6 D0.5 D0.4 D0.3 D0.2 D0.1 D0.0
Bit 7:0 = D4.[7:0]: Channel 4 Data
Bit 7:0 = D0.[7:0]: Channel 0 Data.
CHANNEL 5 DATA REGISTER (D5R)
R245 - Read/Write
Register Page: 63
CHANNEL 1 DATA REGISTER (D1R)
R241 - Read/Write
Register Page: 63
Reset Value: undefined
7
0
Reset Value: undefined
7
0
D5.7 D5.6 D5.5 D5.4 D5.3 D5.2 D5.1 D5.0
D1.7 D1.6 D1.5 D1.4 D1.3 D1.2 D1.1 D1.0
Bit 7:0 = D5.[7:0]: Channel 5 Data.
Bit 7:0 = D1.[7:0]: Channel 1 Data.
CHANNEL 6 DATA REGISTER (D6R)
R246 - Read/Write
Register Page: 63
CHANNEL 2 DATA REGISTER (D2R)
R242 - Read/Write
Register Page: 63
Reset Value: undefined
7
0
Reset Value: undefined
7
0
D6.7 D6.6 D6.5 D6.4 D6.3 D6.2 D6.1 D6.0
D2.7 D2.6 D2.5 D2.4 D2.3 D2.2 D2.1 D2.0
Bit 7:0 = D6.[7:0]: Channel 6 Data
Bit 7:0 = D2.[7:0]: Channel 2 Data.
CHANNEL 7 DATA REGISTER (D7R)
R247 - Read/Write
Register Page: 63
CHANNEL 3 DATA REGISTER (D3R)
R243 - Read/Write
Register Page: 63
Reset Value: undefined
7
0
Reset Value: undefined
D7.7 D7.6 D7.5 D7.4 D7.3 D7.2 D7.1 D7.0
Bit 7:0 = D3.[7:0]: Channel 3 Data.
