I C BUS INTERFACE (Cont’d)
2
2
I C OWN ADDRESS REGISTER (OAR1)
I C OWN ADDRESS REGISTER (OAR2)
Read / Write
Reset Value: 0000 0000 (00h)
Read / Write
Reset Value: 0100 0000 (40h)
7
0
7
0
0
ADD7 ADD6 ADD5 ADD4 ADD3 ADD2 ADD1 ADD0
FR1
FR0
0
0
0
ADD9 ADD8
7-bit Addressing Mode
Bit 7:6 = FR1-FR0 Frequency bits.
Bit 7:1 = ADD7-ADD1 Interface address.
These bits define the I C bus address of the inter-
face. They are not cleared when the interface is
disabled (PE=0).
These bits are set by software only when the inter-
face is disabled (PE=0). To configure the interface
to I C specifed delays select the value corre-
2
2
sponding to the microcontroller frequency F
.
CPU
F
Range (MHz)
2.5 - 6
FR1
FR0
CPU
Bit 0 = ADD0 Address direction bit.
This bit is don’t care, the interface acknowledges
either 0 or 1. It is not cleared when the interface is
disabled (PE=0).
0
0
1
1
0
1
0
1
6 -10
10 - 14
14 - 24
Note: Address 01h is always ignored.
Bit 5:3 = Reserved
Bit 2:1 = ADD9-ADD8 Interface address.
These are the most significant bits of the I C bus
address of the interface (10-bit mode only). They
are not cleared when the interface is disabled
(PE=0).
10-bit Addressing Mode
Bit 7:0 = ADD7-ADD0 Interface address.
These are the least significant bits of the I C bus
address of the interface. They are not cleared
when the interface is disabled (PE=0).
2
2
Bit 0 = Reserved.
