I C BUS INTERFACE (Cont’d)
Figure 45. Transfer Sequencing
7-bit Slave receiver:
S
Address
A
Data1
A
Data1
Data1
Data2
EV3
A
Data2
Data2
DataN
A
P
.....
EV1
EV2
A
EV2
A
EV2
NA
EV4
7-bit Slave transmitter:
S
Address
A
DataN
P
.....
.....
EV1 EV3
EV3
EV3-1
EV4
7-bit Master receiver:
S
Address
A
A
A
DataN NA
P
EV5
EV6
EV7
A
EV7
A
EV7
A
7-bit Master transmitter:
S
Address
A
Data1
Data2
DataN
P
.....
EV5
EV6 EV8
EV8
EV8
EV8
10-bit Slave receiver:
S
Header
A
Address
A
Data1
A
DataN
A
P
.....
EV1
EV2
EV2
EV4
10-bit Slave transmitter:
S
Header
A
Data1
A
A
DataN
....
.
A
P
r
EV1 EV3
EV6 EV8
EV3
EV3-1
EV4
10-bit Master transmitter
S
Header
A
Address
A
Data1
DataN
A
P
.....
EV5
EV9
EV8
A
EV8
A
10-bit Master receiver:
S
Header
A
Data1
DataN
P
r
.....
EV5
EV6
EV7
EV7
Legend: S=Start, S = Repeated Start, P=Stop, A=Acknowledge, NA=Non-acknowledge,
r
EVx=Event (with interrupt if ITE=1)
EV1: EVF=1, ADSL=1, cleared by reading SR1 register.
EV2: EVF=1, BTF=1, cleared by reading SR1 register followed by reading DR register.
EV3: EVF=1, BTF=1, cleared by reading SR1 register followed by writing DR register.
EV3-1: EVF=1, AF=1, BTF=1; AF is cleared by reading SR1 register. BTF is cleared by releasing the
lines (STOP=1, STOP=0) or by writing DR register (DR=FFh). Note: If lines are released by
STOP=1, STOP=0, the subsequent EV4 is not seen.
EV4: EVF=1, STOPF=1, cleared by reading SR2 register.
EV5: EVF=1, SB=1, cleared by reading SR1 register followed by writing DR register.
EV6: EVF=1, cleared by reading SR1 register followed by writing CR register (for example PE=1).
EV7: EVF=1, BTF=1, cleared by reading SR1 register followed by reading DR register.
EV8: EVF=1, BTF=1, cleared by reading SR1 register followed by writing DR register.
EV9: EVF=1, ADD10=1, cleared by reading SR1 register followed by writing DR register.
