IP1001 LF
Data Sheet
4.12 Extended Status Register (Reg15)
HW
Reset Reset
SW
Bit
Name
Description
Type
RO
15[11:0]
15.12
Reserved
Ignore when read
0x000 0x000
1000BASE-T
Half Duplex
1: be able to perform half duplex 1000BASE-T RO
0: not able to perform half duplex 1000BASE-T
1
1
0
0
1
1
0
0
15.13
15.14
15.15
1000BASE-T
Full Duplex
1: be able to perform full duplex 1000BASE-T RO
0: not able to perform full duplex 1000BASE-T
1000BASE-X
Half Duplex
1: be able to perform half duplex 1000BASE-X RO
0: not able to perform half duplex 1000BASE-X
1000BASE-X
Full Duplex
1: be able to perform full duplex 1000BASE-X RO
0: not able to perform full duplex 1000BASE-X
37/48
Dec. 18, 2007
IP1001-DS-R06
