IP1001 LF
Data Sheet
4.7
Bit
Auto-Negotiation Expansion Register (Reg6)
HW
Reset Reset
SW
Name
Description
Type
RO
6.0
Link Partner
1: Link partner supports Auto-Negotiation
0
0
Auto-Negotiation Able 0: Link partner does not support
Auto-Negotiation
6.1
6.2
6.3
6.4
Page Received
1: A new page has been received
0: A new page has not been received
RO
LH
0
1
0
0
0
0
0
0
Local Next Page
Able
1: Local device supports Next Page
0: Local device does not support Next Page
RO
RO
RO
Link Partner Next
Page Able
1: Link Partner supports Next Page
0: Link Partner does not support Next Page
Parallel Detection 1: A fault has been detected via Parallel
Fault
Detection function
0: A fault has not been detected via Parallel
Detection function
6.15:5 Reserved
Ignore when read
RO
Reserve 0
33/48
Dec. 18, 2007
IP1001-DS-R06
Copyright © 2006, IC Plus Corp.
