IP1001 LF
Data Sheet
4.10 1000BASE-T Control Register (Reg9)
HW
Reset Reset
SW
Bit
Name
Description
Type
R/W
9[7:0]
Reserved
Ignore when read
Reserved to
0x00
9.8
1000BASE-T Half 1: Advertise 1000BASE-T half duplex capable R/W
Duplex 0: Not advertise
1000BASE-T Full 1: Advertise 1000BASE-T full duplex capable R/W
1
1
1
0
0
0
0
0
9.9
Duplex
0: Not advertise
9.10
9.11
Port Type
1: Prefer multi-port device (MASTER)
0: Prefer single-port device (SLAVE)
R/W
R/W
Configuration
Value
1: Manual configure as MASTER
0: Manual configure as SLAVE
It is valid only if bit 9.12 is set to 1.
9.12
Manual
Configuration
Enable
1: Manual Configuration Enabled
0: Manual Configuration Disabled
R/W
0
0
9[15:13] Test mode
1000BASE_T test mode defined in IEEE802.3 R/W
clause 40.6.
000
000
9[15:13] Mode
000
001
Normal Mode
Test Mode 1
- Transmit waveform test
010
Test Mode 2 - Transmit Jitter test in
MASTER mode
011
Test Mode 3 - Transmit Jitter test in
SLAVE mode
100
Test Mode 4 - Transmit distortion
test
Others
Reserved
35/48
Dec. 18, 2007
Copyright © 2006, IC Plus Corp.
IP1001-DS-R06
