PIC12F510/16F506
TABLE 13-4: A/D CONVERTER CHARACTERISTICS (PIC12F510)
Param
Sym
Characteristic
Min
Typ†
Max
Units
Conditions
No.
A01
NR
Resolution
—
—
—
—
—
—
8 bits
± 1
bit
A03
A04
EIL
Integral Error
LSb VDD = 5.0V
EDL
Differential Error
-1 < EDL ≤ 1 LSb No missing codes to 8
bits VDD = 5.0V
A05
A06
A07
A10
A25
A30
EFS
EOFF
EGN
—
Full-scale Range
Offset Error
2
—
—
5.5*
± 1
± 1
—
V
VDD
—
LSb VDD = 5.0V
LSb VDD = 5.0V
Gain Error
—
—
Monotonicity
—
guaranteed(2)
—
V
VSS ≤ VAIN ≤ VDD
VAIN
ZAIN
Analog Input Voltage
VSS
—
—
—
VDD
10
RecommendedImpedance
of Analog Voltage Source
kΩ
*
These parameters are characterized but not tested.
†
Data in the “Typ” column is at 5.0V, 25°C unless otherwise stated. These parameters are for design
guidance only are not tested.
Note 1: Total Absolute Error includes integral, differential, offset and gain errors.
2: The A/D conversion result never decreases with an increase in the input voltage and has no missing
codes.
3: VREF current is from external VREF or VDD pin, whichever is selected as reference input.
4: When A/D is off, it will not consume any current other than leakage current. The power-down current
specification includes any such leakage from the A/D module.
DS41268B-page 90
Preliminary
© 2006 Microchip Technology Inc.
