PIC12F510/16F506
DC Characteristics: PIC12F510/16F506 (Industrial)
13.1
Standard Operating Conditions (unless otherwise specified)
Operating Temperature -40°C ≤ TA ≤ +85°C (Industrial)
DC CHARACTERISTICS
Parm
Sym
Characteristic
Min Typ(1) Max Units
Conditions
No.
D001
D002
VDD
VDR
Supply Voltage
2.0
—
—
5.5
—
V
V
See Figure 13-1
RAM Data Retention
Voltage(2)
1.5*
Device in Sleep mode
D003
D004
D010
VPOR VDD Start Voltage to
—
Vss
—
—
—
V
See Section 10.4 “Power-on Reset
(POR)”
ensure Power-on Reset
SVDD VDD Rise Rate to ensure 0.05*
V/ms See Section 10.4 “Power-on Reset
(POR)” for details
Power-on Reset
IDD
Supply Current(3)
—
—
—
—
170 TBD
μA FOSC = 4 MHz, VDD = 2.0V(4)
0.4
1.7
15
TBD mA FOSC = 8 MHz, VDD = 3.0V
TBD mA FOSC = 20 MHz, VDD = 5.0V
TBD
μA FOSC = 32 kHz, VDD = 2.0V, WDT
disabled
D020
D022
D023
D024
D025
IPD
Power-Down Current(5)
—
—
—
—
—
0.1
1.0
15
TBD
TBD
TBD
μA VDD = 2.0V
μA VDD = 2.0V
μA VDD = 2.0V
μA VDD = 2.0V
μA VDD = 2.0V
ΔIWDT WDT Current(5)
ΔICMP Comparator Current
ΔIADC ADC Current
100 TBD
ΔIVREF Internal Reference
80
TBD
Current
D026
ΔCVREF Comparator Voltage
—
58
TBD
μA VDD = 2.0V
Reference Current
Legend: TBD = To be determined.
These parameters are characterized but not tested.
*
Note 1: Data in the Typical (“Typ”) column is based on characterization results at 25°C. This data is for design
guidance only and is not tested.
2: This is the limit to which VDD can be lowered in Sleep mode without losing RAM data.
3: The supply current is mainly a function of the operating voltage and frequency. Other factors such as bus
loading, oscillator type, bus rate, internal code execution pattern and temperature also have an impact on
the current consumption.
a) The test conditions for all IDD measurements in active operation mode are:
OSC1 = external square wave, from rail-to-rail; all I/O pins tri-stated, pulled to VSS, T0CKI = VDD,
MCLR = VDD;
WDT enabled/disabled as specified.
b) For standby current measurements, the conditions are the same, except that the device is in Sleep
mode.
4: Does not include current through REXT (in EXTRC mode only). The current through the resistor can be
estimated by the formula:
I = VDD/2REXT (mA) with REXT in kΩ.
5: The power-down current in Sleep mode does not depend on the oscillator type. Power-down current is
measured with the part in Sleep mode, with all I/O pins in high-impedance state and tied to VDD or VSS.
