Proprietary TranSwitch Corporation Information for use Solely by its Customers
L3M
TXC-03452B
DATA SHEET
TRANSMIT POH BYTES & “O”-BITS
B3 Error Mask
Not
J1
C2
G1
F2
H4
Z3 (F3) Z4 (K3) Z5 (N1)
45 46 47
“O”-bits
used
and Test
00-3F
40
41
42
43
44
48
49
Bits 1-0
RECEIVE POH BYTES, TUG-3 H1/H2 BYTES & “O”-BITS
J1
B3
C2
G1
F2
H4
Z3 (F3) Z4 (K3) Z5 (N1)
95 96 97
H1
H2 “O”-bits
50-8F
90
91
92
93
94
98
99
9A
Bits 1-0
PERFORMANCE COUNTERS & FIFO LEAK RATE
RCV Frame
Count
FIFO Leak
Rate
TUG-3
INC Count DEC Count
TUG-3
Not used
INC Count DEC Count NDF Count
A3 A4 A5
A0
A1
A2
A6 A7
TUG-3
New Data Flag
Count
B3 Block
Error Count
FEBE
Count
B3 Error Line CV/PRBS
Common High Byte
(FEBE, B3, CVs)
Count
Error Count
A8
A9
AA
AC
AE
FF
DEVICE IDENTIFICATION
The device identification (ID) is based on the manufacturer identity, part-number and version codes described
in IEEE standard 1149.1 on Boundary Scan, using the manufacturer code assigned by the Joint Electron
Device Engineering Council (JEDEC). The serial format for this ID is shown below:
MSB
Version
LSB
Part-Number
0000 1101 0111 1100
Manufacturer Identity
000 0110 1011
Fixed Bit
1
(TBD)
4 bits
16 bits
11 bits
1 bit
The device identification is not currently provided as a boundary scan message. However, the manufacturer
identity and part-number are implemented with read-only capability for microprocessor read access. The man-
ufacturer identity for TranSwitch devices is 107 (06B hex.). The part-number of the L3M device is 03452 (0D7C
hex.). In addition, the read-only segment is expanded to include a 4-bit mask level field and a 4-bit future
growth field, as shown below:
Address
(Hex)
Mode
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
F4
F3
F2
F1
F0
R
R
R
R
R
Mask Level - Content TBD
Revision (Version) Level - Content TBD
Growth - Content TBD
PN15=0 PN14=0 PN13=0
PN12=0
PN4=1
MI7=0
1
PN11=1 PN10=1
PN9=0
PN1=0
MI4=0
PN8=1
PN0=0
MI3=1
PN7=0
MI10=0
MI2=0
PN6=1
MI9=0
MI1=1
PN5=1
MI8=0
MI0=1
PN3=1
MI6=1
PN2=1
MI5=1
TXC-03452B-MB
Ed. 6, April 2001
- 62 of 96 -
