Proprietary TranSwitch Corporation Information for use Solely by its Customers
L3M
TXC-03452B
DATA SHEET
INPUT, OUTPUT AND INPUT/OUTPUT PARAMETERS
INPUT PARAMETERS FOR CMOS
Parameter
Min
Typ
Max
Unit
Test Conditions
4.75 < VDD < 5.25
4.75 < VDD < 5.25
DD = 5.25; VIN = 0
VIH
VIL
3.15
V
V
1.65
-10
Input leakage current
Input capacitance
µA
pF
V
3.5
INPUT PARAMETERS FOR TTL
Parameter
Min
Typ
Max
Unit
Test Conditions
VIH
VIL
2.0
V
V
4.75 <VDD < 5.25
4.75 <VDD < 5.25
VDD = 5.25; VIN = 0
0.8
-10
Input leakage current
Input capacitance
µA
pF
3.5
INPUT PARAMETERS FOR TTLp
Parameter
Min
Typ
Max
Unit
Test Conditions
VIH
VIL
2.0
V
V
4.75 < VDD < 5.25
4.75 < VDD < 5.25
0.8
Input leakage current
Input capacitance
-0.5
3.5
-1.4
mA
pF
V
DD = 5.25; VIN = 0
OUTPUT PARAMETERS FOR CMOS 4mA
Parameter
Min
Typ
Max
Unit
Test Conditions
VOH
VOL
IOL
VDD(MIN) - 0.7
V
V
VDD = 4.75; IOH = -4.0
VDD = 4.75; IOL = 4.0
0.4
4.0
-4.0
5.0
4.1
mA
mA
ns
ns
IOH
tRISE
tFALL
1.2
0.9
2.8
2.0
CLOAD = 15pF
CLOAD = 15pF
TXC-03452B-MB
Ed. 6, April 2001
- 25 of 96 -
