Si3035
Bill of Materials
Table 13. Component Values—Typical Application
Component1
Value
Supplier(s)
C1,C4
150 pF, 3 kV, X7R, ±20%
Novacap, Venkel, Johanson, Murata,
Panasonic, SMEC
C2
C3
Not Installed
0.22 µF, 16 V, X7R, ±20%
1 µF, 16 V, Tant/Elec, ±20%
0.1 µF, 16 V, X7R, ±20%
15 nF, 250 V, X7R, ±20%
39 nF, 16 V, X7R, ±20%
2.7 nF, 16 V, X7R, ±20%
C5
C6,C10,C16
C7,C8,C9
C11
Novacap, Johanson, Murata, Panasonic, SMEC
C122
C232
0.1 µF, 16 V, Tant/Elec/X7R, ±20%
1000 pF, 3 kV, X7R, ±10%
Not Installed
C24, C25, C31,C323
C304
Novacap, Venkel, Johanson, Murata, Panasonic, SMEC
Central Semiconductor
D1,D25
D3,D4
FB1,FB2
Q1,Q3
Q2
Dual Diode, 300 V, 225 mA
BAV99 Dual Diode, 70 V, 350 mW
Ferrite Bead
Diodes, Inc., OnSemiconductor, Fairchild
Murata
A42, NPN, 300 V
A92, NPN, 300 V
Sidactor, 275 V, 100 A
MOV, 240 V
OnSemiconductor, Fairchild
OnSemiconductor, Fairchild
Teccor, ST Microelectronics, Microsemi, TI
Panasonic
RV1
RV2
R1
51 Ω, 1/2 W ±5%
15 Ω, 1/4 W ±5%
Not Installed
R2
R36
R42,R18,R212
R5,R6
301 Ω, 1/10 W, ±1%
36 kΩ, 1/10 W ±5%
2 kΩ, 1/10 W ±5%
20 kΩ, 1/10 W ±5%
10 Ω, 1/10 W ±5%
Si3021
R9,R10
R22,R23
R27,R28
U1
Silicon Labs
Silicon Labs
U2
Si3012
Z1
Zener diode, 18 V
Zener diode, 5.6 V, 1/2 W
Vishay, Rohm, OnSemiconductor
Diodes, Inc., OnSemiconductor, Fairchild
Z4,Z5
Notes:
1. The following reference designators were intentionally omitted: C13–C15, C17–C22, C26–C29, R7, R8, R11–R17,
R19, and R20.
2. If JATE support is not required, C12, and C23 may be removed.
3. Alternate population option is C24, C25 (2200 pF, 3 kV, X7R, ±10% and C31, C32 not installed).
4. Install only if needed for improved radiated emissions performance (10 pF, 16 V, NPO, ±10%).
5. Several diode bridge configurations are acceptable (suppliers include General Semi, Diodes Inc.)
6. If the charge pump is not enabled (with the CPE bit in Register 6), VA must be 4.75 to 5.25 V. R3 can be installed with
a 10 Ω, 1/10 W, ±5% if VD is also 4.75 to 5.25 V.
16
Rev. 1.2
