PCT789T-A PCI CONFIGURATION REGISTERS
!!
PCT789T-A PCI CONFIGURATION REGISTERS
PCI Configuration Register Summary
Table 14 PCI Configuration Registers
Index
00h
04h
08h
0Ch
10h
14h
18h
1Ch
20h
24h
28h
2Ch
30h
34h
38h
3Ch
40h
PCI Configuration Register
Device ID
Status
Vendor ID
Command
Class code
Revision ID
Reserved a
Base address 0 (Control registers)
Reserved a
Reserved a
Reserved a
Reserved a
Reserved a
Reserved a
Subsystem ID
Reserved a
Reserved a
Subsystem vendor ID
Capability pointer
Reserved a
Reserved a
Interrupt pin
Interrupt line
Power management
capabilities
Next-item pointer
Capability identifier
Reserved a
44h
Power management control/status
Reserved a
48h-FFh
a. All reserved registers return 0 when read.
