TrueSpeech® Co-Processor
PRELIMINARY/CONFIDENTIAL
Version: 1.18
5 CT8022 CODEC Interface
DX0
DR0
CODEC
0
47K
47K
47K
Optional second CODEC for
Full-Duplex Speakerphone
SCLK
Host
CT8022
CODEC 1 connects to
microphone and speaker
FSYNC
CODEC
1
DX1
DR1
47K
Figure 5-1:
CT8022 CODEC Interface Connection
In Master mode, the CT8022 generates the FSYNC and SCLK signals.
In Slave mode, the FSYNC and SCLK signals are generated externally. In slave mode, the CT8022 FSYNC and
SCLK pins are inputs.
Note: During and after reset, the SCLK and FSYNC pins are configured as inputs. As such, they require
external pull-down resistors to ensure that a safe and defined logic level is present.
5.1
CODEC Options
The CT8022 CODEC interface supports the following features:
•
•
•
•
CODEC clock master or slave
8-bit A-law/µ-law or 16-bit linear CODEC
Short or Long FSYNC
Programmable SCLK and FSYNC clock rates
40
