Mnemonic:
Pad and Pin No.:
Pin Type:
Description:
VCCCM
45
PWR
Positive supply pin for output stage operating point control sys-
tem. Connect to VCCCONT.
VCCR
VEE
7, 12
PWR
PWR
Positive supply pin for re-timing part.
13, 17, 24, 34, 37,
43, 47
Negative supply pins for laser driver and control circuit part.
VEER
NC
1, 2
21
PWR
Negative supply pin for re-timing part.
Not connected.
Heat sink
Package backside
Connected to VEE.
Package Pinout
1
36
VEER
MARKN
2
35
VEER
MARKP
3
34
TDIP
VEE
4
33
SDIP
VCC
5
32
SDIN
IMB
6
31
TDIN
IMB
7
30
VCCR
IM
8
29
TCIP
IM
9
28
SCIP
VCC
10
27
SCIN
IB
11
26
TCIN
PD
12
25
VCCR
AR
Figure 11.Package Pinout, Top View.
Data Sheet Rev.: 11
GD16521
Page 7 of 13
