MODE_SELECT Register
The Mode_Select register allows the LSP
of the AS91L1006BU to be connected in various
different configurations. A LSP is selected for
connection within the scan chain by the contents of
the Mode_Select register.
i.e.: Pause-DR, Pause-IR, Run-Test-Idle or Test-
Logic-Reset, it will be connected into the active
scan chain. If all LSPs are parked in a stable
state, then the AS91L1006BU will perform a
bypass of the 6-LSP chain section. In this way if
both sections are in the bypass mode then the
AS91L1006BU is performing a loopback of TDI-
>Register->TDO to the host device.
Mode_Select
LSP Configuration (If Port
Register (Bit 15
Unparked)
Mode_Select
LSP Configuration (If Port
Register (Bit 7 ->
Unparked)
-> Bit 8)
Bit 0)
XXX0X000
XXX0X001
XXX0X010
XXX0X011
TDI ->Register->LSP_Data
XXX0X000
XXX0X001
XXX0X010
XXX0X011
LSP_Data ->TDO
TDI ->Register->LSP1->PAD->
LSP_Data
LSP_Data ->LSP4->PAD-
>TDO
TDI ->Register->LSP2->PAD->
LSP_Data
LSP_Data ->LSP5->PAD-
>TDO
TDI ->Register->LSP1->PAD-
>LSP2->PAD-> LSP_Data
LSP_Data ->LSP4->PAD-
>LSP5->PAD->TDO
XXX0X100
XXX0X101
TDI ->Register->LSP3->PAD->
LSP_Data
XXX0X100
XXX0X101
LSP_Data ->LSP6->PAD-
>TDO
TDI ->Register->LSP1->PAD-
>LSP3->PAD-> LSP_Data
LSP_Data ->LSP4->PAD-
>LSP6->PAD->TDO
XXX0X110
XXX0X111
TDI ->Register->LSP2->PAD-
>LSP3->PAD-> LSP_Data
XXX0X110
XXX0X111
LSP_Data ->LSP5->PAD-
>LSP6->PAD->TDO
TDI ->Register->LSP1->PAD-
>LSP2->PAD->LSP3->PAD->
LSP_Data
LSP_Data ->LSP4->PAD-
>LSP5->PAD->LSP6->PAD-
>TDO
Table 7 - Mode Select Register Mapping
X = Don’t care
Register = AS91L1006BU device instruction register or any of the AS91L1006BU device test
data registers.
PAD = Insertion of a 1-bit register for data synchronization.
Upon entering Test-Logic-Reset, the register bits will be loaded with “0000000”.
