AS91L1006BU device Register descriptions
Bypass Register
It is a mandatory single bit register that can
Multi-Cast Group Register
This 2-bit data register enables the host
be connected between PRIM_TDI and PRIM_TDO
of the AS91L1006BU device.
system to place the AS91L1006BU into one of
four distinct addressable groups.
MCGR Register Bits Binary Selection Address
MCGR GROUP
GRP0
[1..0]
00
01
10
11
XX111100
XX111101
XX111110
XX111111
GRP1
GRP2
GRP3
Table 5 - Multicast Group Register Mapping
ꢁNote: The MCGR is reset to 00 upon receiving TRST or the entering of the Test-Logic-Reset
state.
Bits 12 to 27 indicate the part number of the
device: “0000000000010000”
IDCODE Register
It is an optional 32-bit register that can be
Bits 28 to 31 indicate the revision of the device:
“0000”
connected between PRIM_TDI and PRIM_TDO of
the AS91L1006BU device. The contents of the
IDCODE register will be loaded with the following
data when the AS91L1006BU enters Test-Logic-
Reset or passes through Capture-IR:
USERCODE Register
The USERCODE is an 8-bit register that can
be addressed via standard IEEE1149.1
commands, which are automatically generated by
third party test tools. AS91L1006BU returns all
zeroes if read from this registerUSERUSER and
does have the ability to write into this register.
"00000000000000001000001101101111"
Bits 0 to 11 indicate ALSC Jedec ID value of:
“001101101111”
ꢁ
* The AS91L1006BU is a complete second source and pin for pin replacement of the
Firecron JTS06BU device.
