MVTX2801
Data Sheet
Ball No(s)
Symbol
LA_A[19:3]
I/O
Description
AA1, V5, AA2, AA3,
Y1, V4, Y2, Y3, U5,
W1, W2, W3, T5, V1,
V2, P4, V3
Output
Frame Bank A - Address Bit [19:3]
W4
C2
K3
LA_A[20]
LA_CLK
LA_CS0#
Output with pull up
Output
Output with pull up
Frame Bank A - Address Bit [20]
Frame Bank A Clock Input
Frame Bank A Low Portion Chip
Selection
L1
LA_CS1#
Output with pull up
Frame Bank A High Portion Chip
Selection
L2
LA_RW#
Output with pull up
I/O-TS with pull up.
Frame Bank A Read/Write
No Connect
D18, B18, C18, A17, NC
E17, B17, C17, E16,
D17, B16, E15, C16,
D16, D15, E14, C15,
B15, E13, A15, D14,
C14, D13, B14, A14,
C13, E12, B13, A13,
D12, C12, B12, A12,
A11, E10, C10, B10,
E9, A10, D11, D10,
D8, D9, C9, B9, A9,
C8, B8, A8, C7, E7,
D7, B7, E8, A7, D6,
C6, E6, B6, A6, A5,
B5, C5, B4,A4
D22, D20, E20, D21, NC
A21, D19, B21, C21,
A20, B20, E19, C20,
A19, B19, E18, C19,
A18
Output
F
D5
B11
E11
C11
LB_A[20]
Output with pull up
Output
Output with pull up
Output with pull up
Output with pull up
Bootstrap Pin
NC
NC
NC
NC
Switch Database Interface
E24,B27, D27, C27,
A27, A28, B30, D28,
E27, C30, D30, G26,
E28, D29, E26, E29,
H26, E30, J26, F30,
F29, F28, F27, H27,
G30, G29, K26, G27,
G28, H30, H29, M27
B_D[31:0]
I/O-TS with pull up
Switch Database Domain
- Data Bit [31:0]
