MVTX2801
Data Sheet
Ball No(s)
Symbol
I/O
Description
V26, W29, W30, Y28, NC
W26, Y29, W27, Y30
AB26, AE27, AE28,
AC27, AE29, AC26,
AE30, AD26
AK27, AH27, AF26,
AJ27, AH26, AK25,
AG26, AJ25
AG22, AG21, AG20,
AF22, AK21, AK20,
AF21, AJ20
AH16, AH10, AK5,
G[3:0]_RX_D[8]
NC
Input w/ pull down
Input w/ pull up
Input w/ pull up
Input w/ pull up
Output
G[3:0]port - PMA Receive Data Bit [8]
G[3:0]port - PMA Receive Data Bit [9]
G[3:0]port - PMA Receive Clock 1
G[3:0]port - PMA Receive Clock 0
AD5
W28, AD30, AK28,
AH22,
AF19, AG12, AK6,
G[3:0]_RX_D[9]
NC
AF2
V27, AD27, AJ28,
AH23,
AF14, AK10, AJ4,
G[3:0]_RXCLK1
NC
AD3
AA28, AF29, AJ26,
AJ21,
AH14, AG10, AH5,
G[3:0]_RXCLK0
NC
AC1
AA29, AF27, AK26,
AH21,
AK14, AF13, AH13,
AK13, AH12, AJ12,
AF12, AK12
G3_TXD[7:0]
G[3:0]port - PMA Transmit Data Bit
[7:0]
AF8, AJ8, AK8, AG7, G2_TXD[7:0]
AG8, AJ7, AK7, AF7
AG4, AK1, AJ1, AJ2,
AH2, AH1, AG1, AE5 G1_TXD[7:0]
AA5, AD4, AC2, Y5,
AC3, AB2, W5, AB3
G0_TXD[7:0]
Table 8 - Ball- Signal Descriptions (continued)
80
Zarlink Semiconductor Inc.
