10.7.7 MIIC3 - MII Command Register 3
Serial Interface Address:h606
Accessed by serial interface (R/W)
7
6
5
4
0
Rdy
Valid
PHY address
Bits [4:0]:
Bit [6]
•
•
•
PHY_AD - 5 Bit PHY Address
VALID - Data Valid from PHY (Read Only)
Bit [7]
RDY - Data is returned from PHY (Ready Only)
Note: Before programming MII command: set FEN[6], check MIIC3, making sure no RDY and no VALID; then
program MII command.
10.7.8 MIID0 - MII Data Register 0
Serial Interface Address:h607
Accessed by serial interface (RO)
Bit [7:0]
•
MII Data [7:0]
10.7.9 MIID1 - MII Data Register 0
Serial Interface Address:h608
Accessed by serial interface (RO)
Bit [7:0]
•
MII Data [15:8]
10.7.10 LED Mode - LED Control
2
I C Address:h0B4; Serial Interface Address:h609
2
Accessed by serial interface and I C (R/W)
7
6
5
4
3
2
1
0
lpbk
Out Pattern
Clock rate
Hold Time
Bit[1:0]
•
Sample hold time (Default 2'b00)
2'b00- 8 msec
2'b01- 16 msec
2'b10- 32 msec
2'b11- 64 msec
