MVTX2801
Data Sheet
10.7 Group 6 Address - MISC Group
10.7.1 MII_OP0 - MII Register Option 0
2
I C Address h0B1, Serial Interface Address:h600
2
Accessed by serial interface and I C (R/W)
7
6
5
4
0
Hfc
1prst
NP
Vendor Spc. Reg Addr
Bit [7]:
•
Half duplex flow control no default enable (Do not use half duplex mode)
- 0 = Half duplex flow control always enable
- 1 = Half duplex flow control by negotiation
Bit[6]:
Bit [5]
•
•
Link partner reset auto-negotiate disable
Next page enable
- 1: enable
- 0: disable
Bit[4:0]:
•
Vendor specified link status register address (null value means don't use it) (Default 00)
10.7.2 MII_OP1 - MII Register Option 1
2
I C Address 0B2, Serial Interface Address:h601
2
Accessed by serial interface and I C (R/W)
7
4
3
0
Speed bit location
Duplex bit location
Bits[3:0]:
Bits [7:4]:
•
•
Duplex bit location in vendor specified register
Speed bit location in vendor specified register (Default 00)
10.7.3 FEN - Feature Register
2
I C Address h0B3, Serial Interface Address:h602
2
Accessed by serial interface and I C (R/W)
7
6
5
3
2
1
0
DML
MII
DS
61
Zarlink Semiconductor Inc.
