MVTX2801
Data Sheet
10.6.81 QOSC75 - TOKEN_RATE_G1
Serial Interface Address:h58C
Bits [7:0]
•
Bytes allow to transmit every frame time (0.512usec) when regulated by
Shaper logic. (Default: 8'h08)
10.6.82 QOSC76 - TOKEN_LIMIT_G1
Serial Interface Address:h58D
Bits [7:0]
•
Bytes allow to continue transmit out when regulated by Shaper logic.
(16byte/unit) (Default: 8'hC0)
QOSC75 and QOSC76 correspond to parameters from section 7.6 on the shaper for EF traffic. QOSC75 is an
integer less than 64, with granularity 1. QOSC76 is the programmed maximum value of the counter (maximum burst
size). This value is expressed in multiples of 16. QOSC75 and QOSC76 apply to Gigabit port 1. Register
QOSC41-CREDIT_C6_G1 programs the peak rate. See QoS application note for more information.
Class 6 Shaper Control Port G2
10.6.83 QOSC77 - TOKEN_RATE_G2
Serial Interface Address:h58E
Bits [7:0]
•
Bytes allow to transmit every frame time (0.512usec) when regulated by
Shaper logic. (Default: 8'h08)
10.6.84 QOSC78 - TOKEN_LIMIT_G2
Serial Interface Address:h58F
Bits [7:0]
•
Bytes allow to continue transmit out when regulated by Shaper logic.
(16byte/unit) (Default: 8'hC0)
QOSC77 and QOSC78 correspond to parameters from section 7.6 on the shaper for EF traffic. QOSC77 is an
integer less than 64, with granularity 1. QOSC78 is the programmed maximum value of the counter (maximum burst
size). This value is expressed in multiples of 16. QOSC77 and QOSC78 apply to Gigabit port 2. Register
QOSC49-CREDIT_C6_G2 programs the peak rate. See QoS application note for more information.
Class 6 Shaper Control Port G3
10.6.85 QOSC79 - TOKEN_RATE_G3
Serial Interface Address:h590
Bits [7:0]
•
Bytes allow to transmit every frame time (0.512usec) when regulated by
Shaper logic. (Default: 8'h08)
59
