Initialisation MT312
3.5.3 System Clock Frequency. Register 34 (R/W)
Def
hex
NAME
ADR
B7
B6
B5
B4
B3
B2
B1
B0
SYS CLK
34
SYS CLK[7:0] - System clock frequency x2 in MHz
R/W
00
SYS CLK[7:0] = System clock frequency * 2 in MHz.
The SYS CLK register must be programmed to indicate the system clock frequency to the calculation unit. The
maximum system clock frequency allowed is 90MHz.
e.g. for a crystal frequency = 10MHz, if the PLL multiplication ratio is 9,
The system clock frequency = 90MHz.
Then SYS CLK[7:0] = 180.
The system clock frequency is NOT affected by the setting of SYS CLK[7:0] register.
3.6 MT312 Initialisation Read Register
3.6.1 Identification. Register 126 (R)
Def
hex
NAME
ADR
B7
B6
B5
B4
B3
B2
B1
B0
ID
126
ID[7:0] Chip identification.
R
03
ID[7:0]:
This register provides an identification number related to the MT312 version.
23
