Artix-7 FPGAs Data Sheet: DC and AC Switching Characteristics
Table 14: Artix-7 Device Production Software and Speed Specification Release (Cont’d)
Speed Grade
Device
1.0V
0.95V
-1LI
0.9V
-2LE
-3
-2
-2LE
-1
-1Q
-1M
XC7A50T
XC7A75T
XC7A100T
XC7A200T
XA7A12T
XA7A15T
XA7A25T
XA7A35T
XA7A50T
XA7A75T
XA7A100T
Vivado tools 2013.4 v1.11
N/A
N/A
Vivado tools
2014.4 v1.14 2013.4 v1.08
Vivado tools
Vivado tools 2013.3 v1.10
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
Vivado tools Vivado tools
2014.4 v1.14 2013.3 v1.07
ISE tools 14.4 or Vivado tools 2012.4 with the
14.4/2012.4 device pack v1.07
Vivado tools
2014.4 v1.14
ISE tools 14.5
or Vivado
tools 2013.1
Vivado tools
2014.4 v1.14
ISE tools 14.4 or Vivado tools 2012.4 with the
14.4/2012.4 device pack v1.07
v1.05
N/A
N/A
N/A
N/A
N/A
N/A
N/A
Vivado tools
2018.1 v1.15
N/A
N/A
N/A
N/A
N/A
N/A
N/A
Vivado tools 2018.1 v1.15
Vivado tools 2014.4 v1.14
Vivado tools 2018.1 v1.15
Vivado tools 2014.1 v1.09
Vivado tools 2014.1 v1.09
Vivado tools 2014.1 v1.09
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
Vivado tools
2014.4 v1.14
Vivado tools
2018.1 v1.15
Vivado tools
2014.1 v1.09
Vivado tools
2014.1 v1.09
Vivado tools
2014.1 v1.09
ISE tools 14.5
or Vivado tools
2013.1 v1.05
ISE tools 14.5 ISE tools 14.6
or Vivado tools or Vivado tools
2013.1 v1.05
2013.2 v1.06
XQ7A50T
N/A
N/A
Vivado tools
2014.2 v1.08
N/A
N/A
Vivado tools
2014.2 v1.08
N/A
Vivado tools
2014.2 v1.08 2015.4 v1.11
Vivado tools
N/A
N/A
XQ7A100T
ISE tools 14.5
or Vivado tools
2013.1 v1.04
ISE tools 14.5
or Vivado tools
2013.1 v1.04
N/A
N/A
ISE tools 14.6 Vivado tools
orVivadotools 2015.4 v1.11
2013.2 v1.05
XQ7A200T
N/A
ISE tools 14.5
or Vivado tools
2013.1 v1.04
N/A
ISE tools 14.5
or Vivado tools
2013.1 v1.04
ISE tools 14.6
orVivadotools 2015.4 v1.11
2013.2 v1.05
Vivado tools
N/A
Selecting the Correct Speed Grade and Voltage in the Vivado Tools
It is important to select the correct device speed grade and voltage in the Vivado tools for the device that you are selecting.
To select the 1.0V speed specifications in the Vivado tools, select the Artix-7, XA Artix-7, or Defense Grade Artix-7Q
sub-family, and then select the part name that is the device name followed by the package name followed by the speed
grade. For example, select the xc7a100tfgg676-3 part name for the XC7A100T device in the FGG676 package and -3 (1.0V)
speed grade or select the xc7a100tfgg676-2L part name for the XC7A100T device in the FGG676 package and -2LE (1.0V)
speed grade.
To select the -1LI (0.95V) speed specifications in the Vivado tools, select the Artix-7 sub-family and then select the part
name that is the device name followed by an “i” followed by the package name followed by the speed grade. For example,
select the xc7a100tifgg676-1L part name for the XC7A100T device in the FGG676 package and -1LI (0.95V) speed grade.
The -1LI (0.95V) speed specifications are not supported in the ISE tools.
To select the -2LE (0.9V) speed specifications in the Vivado tools, select the Artix-7 Low Voltage sub-family and then select
the part name that is the device name followed by an “l” followed by the package name followed by the speed grade. For
example, select the xc7a100tlfgg676-2L part name for the XC7A100T device in the FGG676 package and -2LE (0.9V) speed
grade.
DS181 (v1.25) June 18, 2018
www.xilinx.com
Product Specification
