Spartan-3E FPGA Family: Functional Description
FPGA passes configuration data via its DOUT output pin to
the next FPGA on the falling CCLK edge.
Table 66: Slave Serial Mode Connections
Pin Name
FPGA Direction
Description
During Configuration
After Configuration
User I/O
HSWAP
Input
User I/O Pull-Up Control. When Drive at valid logic level
Low during configuration, enables throughout configuration.
pull-up resistors in all I/O pins to
respective I/O bank V
input.
CCO
0: Pull-up during configuration
1: No pull-ups
M[2:0]
Input
Mode Select. Selects the FPGA
configuration mode. See Design
Considerations for the HSWAP,
M[2:0], and VS[2:0] Pins.
M2 = 1, M1 = 1, M0 = 1 Sampled User I/O
when INIT_B goes High.
DIN
Input
Input
Data Input.
Serial data provided by host.
FPGA captures data on rising
CCLK edge.
User I/O
User I/O
CCLK
Configuration Clock. If CCLK
PCB trace is long or has multiple
connections, terminate this output
to maintain signal integrity. See
CCLK Design Considerations.
External clock.
INIT_B
Open-drain
Initialization Indicator. Active
Active during configuration. If
CRC error detected during
configuration, FPGA drives
INIT_B Low.
User I/O. If unused in the
application, drive INIT_B
High.
bidirectional I/O Low. Goes Low at start of
configuration during Initialization
memory clearing process.
Released at end of memory
clearing, when mode select pins
are sampled. In daisy-chain
applications, this signal requires
an external 4.7 kΩ pull-up resistor
to VCCO_2.
DONE
Open-drain
FPGA Configuration Done. Low Low indicates that the FPGA is not Pulled High via external
bidirectional I/O during configuration. Goes High
when FPGA successfully
yet configured.
pull-up. When High,
indicates that the FPGA
successfully configured.
completes configuration. Requires
external 330 Ω pull-up resistor to
2.5V.
PROG_B
Input
Program FPGA. Active Low.
Must be High to allow
Drive PROG_B Low and
release to reprogram
FPGA.
When asserted Low for 500 ns or configuration to start.
longer, forces the FPGA to restart
its configuration process by
clearing configuration memory and
resetting the DONE and INIT_B
pins once PROG_B returns High.
Recommend external 4.7 kΩ
pull-up resistor to 2.5V. Internal
pull-up value may be weaker (see
Table 78). If driving externally with
a 3.3V output, use an open-drain
or open-collector driver or use a
current limiting series resistor.
