Product Preview
WM8983
REGISTER
ADDRESS
BIT
LABEL
DEFAULT
DESCRIPTION
R45
5:0
INPPGAVOLL
010000
Left channel input PGA volume
Left channel
input PGA
volume
000000 = -12dB
000001 = -11.25db
.
control
010000 = 0dB
.
111111 = +35.25dB
6
7
INPPGAMUTEL
INPPGAZCL
0
0
Mute control for left channel input PGA:
0 = Input PGA not muted, normal
operation
1 = Input PGA muted (and disconnected
from the following input BOOST stage).
Left channel input PGA zero cross
enable:
0 = Update gain when gain register
changes
1 = Update gain on 1st zero cross after
gain register write.
8
INPPGAVU
Not
latched
INPPGA left and INPPGA right volume
do not update until a 1 is written to
INPPGAVU (in reg 45 or 46)
(See "Volume Updates" below)
R46
5:0
INPPGAVOLR
010000
Right channel input PGA volume
Right
000000 = -12dB
channel
input PGA
volume
control
000001 = -11.25db
.
010000 = 0dB
.
111111 = +35.25dB
6
7
INPPGAMUTER
INPPGAZCR
0
0
Mute control for right channel input
PGA:
0 = Input PGA not muted, normal
operation
1 = Input PGA muted (and disconnected
from the following input BOOST stage).
Right channel input PGA zero cross
enable:
0 = Update gain when gain register
changes
1 = Update gain on 1st zero cross after
gain register write.
8
INPPGAVU
ALCSEL
Not
latched
INPPGA left and INPPGA right volume
do not update until a 1 is written to
INPPGAVU (in reg 45 or 46)
(See "Volume Updates" below)
ALC function select:
00 = ALC off
R32
8:7
00
ALC control
1
01 = ALC right only
10 = ALC left only
11 = ALC both on
Table 5 Input PGA Volume Control
PP Rev 1.1 August 2005
23
